Best Price H.264 IP Video Cable TV Digital Cable HD Encoder IPTV Encoder For Youtube Facebook
- Category: >>>
- Supplier: Chengdu Ustarlink Technology Co. Ltd.
Share on (1600517828756):
Product Overview
Description
Product
Best Price H.264 IP Video Cable TV Digital Cable HD Encoder IPTV Encoder For Youtube Facebook
Technical specification
Input | 4/8/12×HD input (1.4), HDCP 1.4---OptionⅠ 4/8/12×SDI input---OptionⅡ | |||
Video Encoding | Encoding Format | HEVC/ H.265 , MPEG 4 AVC/H.264 | ||
Resolution | HD | 3840×2160_30P, 3840×2160_29.97P (Encoding 2 CHs per module for H.265, and encoding 1 CH for H.264 ) 1920×1080_60P,1920×1080_59.94P,1920×1080_50P, (Encoding 4 CHs per module for H.265, and encoding 2 CHs for H.264) 1280×720_60P, 1280×720_59.94P, 1280×720_50P (Encoding 4 CHs per module for H.264 and H.265) | ||
SDI | 1920×1080_60P,1920×1080_59.94P,1920×1080_50P, (Encoding 4 CHs per module for H.265, and encoding 2 CHs for H.264) 1280×720_60P, 1280×720_59.94P, 1280×720_50P (Encoding 4 CHs per module for H.264 and H.265) | |||
Input: 1920×1080_60i,1920×1080_59.94i,1920×1080_50i Output: 1920×1080_60P,1920×1080_59.94P,1920×1080_50P (Encoding 4 CHs per module for H.265, and encoding 2 CHs for H.264) | ||||
Chroma | 4:2:0 | |||
Bitrate | 0.5Mbps~20Mbps (each channel) | |||
Rate Control | CBR/VBR | |||
GOP Structure | IBBP, IPPP | |||
Advanced Pretreatment | De-interlacing, Noise Reduction, Sharpening | |||
Audio Encoding | Encoding Format | MPEG-1 Layer 2, LC-AAC, HE-AAC, HE-AAC V2, AC3 Passthrough | ||
Sampling rate | 48KHz | |||
Bit-rate (each channel) | 48Kbps-384Kbps (MPEG-1 Layer 2 & LC-AAC) 24 Kbps-128 Kbps (HE-AAC) 18 Kbps-56 Kbps (HE-AAC V2) | |||
Audio Gain | 0~255 | |||
Stream output | IP (1 MPTS and maximum 4 SPTS) output over UDP/RTP/RTSP per module, 1000M/100M Base-T Ethernet interface (unicast/ multicast); IPv4, IPv6 output IP null packet filter | |||
System | Web based management | |||
Chinese-English control interface | ||||
Ethernet software upgrade | ||||
Miscellaneous | Dimension (W× L× H) | 482mm×328mm×44mm | ||
Approx weight | 5kg | |||
Temperature | 0~45℃(work), -20~80℃(Storage) | |||
Power | AC 100V-220V±10%, 50/60Hz | |||
I-frames are the least compressible but don't require other video frames to decode.
P-frames can use data from previous frames to decompress and are more compressible than I-frames.
B-frames can use both previous and forward frames for data reference to get the highest amount of data compression.
Frame Type | Byte of data/KB | Compression Ratio |
I | 18 | 7:1 |
P | 6 | 20:1 |
B | 2.5 | 50:1 |
ET-9204-4 4Channels H.265 IPTV Encoder
Audio Video Input | Video Input | 1-4 Channels HD |
Audio Input | 1-4 Channel HD internal Audio | |
Video Encoding | Encoding Type | H.264/H.265 |
H.264 Level | Baseline /Main /High Optional | |
Encoding Frame rate | 5-60 Adjustable | |
Key Frame Interval(Frame) | 5-300 Adjustable | |
Bitrate (kbit) | 32-32000 Adjustable | |
Resolution | 3840x2160/1920x1080/1680x1056/1280x720/1024x576 /850x480/720x576/720x540/720x480/720x404/704x576 /640x480/640x360/608x448/544x480/480x480/480x384 /480x360/480x320/480x272/480x270/400x320/400x224 /352x480/352x228/320x256/320x240/320x180/240x180/ same as input signals resolution | |
Bitrate Control | Cbr/vbr optional | |
IP Streaming output | Support RTMP/ RTSP /HTTP TS/HTTP FLV/HLS/UDP multicast /RTPmulticast | |
Audio Encoding | Encoding Sampling rate | 44100/48000 optional |
Encoding Way | AAC/AAC+/AAC++/MP3/MP2/AC3 optional | |
Audio Input | Digital/Analog/Mix | |
Encoding bitrate | AAC:48000-256000 adjustable /AAC+:24000-48000 adjustable AAC++:12000-32000 adjustable /MP3:64000-320000 adjustable / MP2: 64000-320000 adjustable / AC3:40000-640000 adjustable | |
Digital Volumn | -50~50 adjustable | |
RTSP Streaming using G711A Encoding | Off/on , with 8K sampling optional | |
OSD | Transparency | 0-128 adjustable |
Text/picture/rolling text | off/on optional | |
Letter size | 8-72 | |
X location | 0-1920 | |
Y location | 0-1080 | |
LOGO | Support two LOGOs, optional | |
Physical Spec. | Network | IP Giga Network |
Management | WEB management | |
Power Supply | 12V/DC,2A | |
Power Consumption | <5W | |
Working Temperature | -20℃+60℃ | |
Working Humidity | <90% | |
L*W*H | 8.0cmX11.2cmX4.0cm (single channel HD input) 11.2cmX17.6cmX4.0cm(four channels HD input ) |
About us
Product categories
Working principle
Packing and shipping
FAQ
Q1: How could I test IPTV system?
We will provide on-line test by our cloud server or help install local server for customer test.
Q2: Could I add some function or design UI interfaces ?
Yes, We have powerful R&D strength to tailor customer's requirements.
Q3: How to make an order?
You can contact our sales by email, whatsapp, skype for quotation.
Q4: How to make payment?
You can make payment by bank TT, western union, Alipay, Paypal etc...
Q5: How about technical support?
We will provide on-line support by teamviewer or on-site support for our customer.
