32 awg Enameled Copper Wire Class Standard Iec 600317 Neodymium Magnet Enameled Copper Wire Class 180C Grade 2
32 awg Enameled Copper Wire Class Standard Iec 600317 Neodymium Magnet Enameled Copper Wire Class 180C Grade 2
32 awg Enameled Copper Wire Class Standard Iec 600317 Neodymium Magnet Enameled Copper Wire Class 180C Grade 2
32 awg Enameled Copper Wire Class Standard Iec 600317 Neodymium Magnet Enameled Copper Wire Class 180C Grade 2
32 awg Enameled Copper Wire Class Standard Iec 600317 Neodymium Magnet Enameled Copper Wire Class 180C Grade 2
32 awg Enameled Copper Wire Class Standard Iec 600317 Neodymium Magnet Enameled Copper Wire Class 180C Grade 2
32 awg Enameled Copper Wire Class Standard Iec 600317 Neodymium Magnet Enameled Copper Wire Class 180C Grade 2

32 awg Enameled Copper Wire Class Standard Iec 600317 Neodymium Magnet Enameled Copper Wire Class 180C Grade 2

Share on (1600517886554):


Price:

Quantity:


Product Overview

Description



Product Description


Main Application Of Enameled Copper Wire

1-Sealed motor working under high temperature
2-Transformer
3-Modern instrument
4-Generator
5-Welding machine



 SWG AWG Submersible Motor Winding Wire Copper Conductor Enamelled Wire For Motor

Enameled copper wire
Type
Q(ZY/XY)-1/200
Diameter
0.27mm
Standard
IEC60317
Test Item
Unit
Technical Requirement
Test Result
Elongation
>=22 %
30%
spring-back angle
<=47
43
Flexibility and adhesion
winding test
1D
1
Jerk test
No Crack, and No losing adhesion
ok
Heat shock
0.630mm
ok
Cut-through resistance
cut-through resistance
2
Breakdown Voltage
KV
>=2.2 KV
7.6 7.0 6.8 6.2 7.7
Scratch Resisting(Average)
N
3.25 N
7.98
Scratch resisting(Min)
N
2.75 N
7.12




Main Features

1) Enameled Copper Wire is one kind of magnet wire which is consisted of bare round copper which accord with EN 13601Cu-ETP standard as the conductor and multi-layer insulation layers. The multi-layer insulation layers can be polyester, modified polyester or polyester-imide and so on.


2) Our Enameled Round Copper Wire is one kind of enameled wire which has high heat resistance. Its temperature class can be from 130℃ to 220℃.


3) Our Enameled Round Copper Wire uses TU2 oxygen-free copper as raw material.TU2 oxygen-free copper has good conductivity and heat conductivity.



Has factory stock, above specifications
if LP Industry has factory stock of enameled round copper wire, clients can buy sample or small quantity


Certifications




Detailed Images


Main Features

Brand Enamel: ELANTAS
Diameter: Continuous production for wide-range of different sizes.
Features: Double or Three Type Insultaions covered wires are available.
Service:Free techincal consultation and suggestion.





Our Service


Perfect Quality Test Equipment

* A full set of product testing equipment.

* Strictly Testing.

* High quality samples for testing.

Export World-Magnet wire

* Our product are exported to more than 50 countries around the world.

* Cooperated with more than 200 overseas customers.





Company Profile




Packing & Delivery




Related Products




FAQ


[Q]: How about your company’s annual production capacity?
A : Our Company’s annual production is about 8,000 tons.

[Q]:What’s your company ‘s product scope?
A : We have many kinds of products ,such as enameled aluminum wire, enameled cooper wire, paper covered magnet wire, fiber glass covered magnet wire and other aluminum/cooper magnet wire products.

[Q]: What’s the temperature-resist grade of your enameled aluminum wire?
A : We produce the thermal class of enameled aluminum wire from 130 to 220 Centigrade.

[Q]: What is specifications of enameled aluminum wire your company can produce?
A : Gauge of enameled aluminum wire:
Enameled round aluminum wire: 0.2mm-8.0mm
Enameled flat aluminum wire: a: 1-6mm, b: 3-16mm

[Q]: Can you offer Round Enameled wire with PEW, C200?
A : Yes, for favorable offer, There is one problem need confirm again, PEW is for Class 155 or 180, not Class 200.

[Q]: Could you provide the free samples?
A : Yes, We could provide the free sampels within 0.5kg. You only need undertake the express charges.

[Q]: What’s the price of your enameled aluminum wire?
A : Please sent an email to our [https://magnetwire.en.alibaba.com ] or a fax to 0086-371-65861123, our salesman will reply you as soon as possible.
