high quality 3 axis cnc controller with macro function cnc controller g code cnc controller lathe similar with kuka fanuc
- Category: >>>
- Supplier: Chengdu Newker CNC-Technology Co. Ltd.
Share on (1600517899730):
Product Overview
Description
VR
Parameter details | ||||||
System Function | G code shows | |||||
number of control axis | 2~4 (X,Y,Z,A) | Locate rapidly: | G00 | |||
The smallest programming: | 0.001mm | Straight line interpolation | G01 | |||
The most programming: | ±99999.999mm | Arc interpolation: | G02/03 | |||
Feed speed: | 30m/min | Thread cut: | G32 | |||
Continuous manual: | one axis or multiple axis at the same time | high speed deep drilling loop | G73 | |||
Line interpolation: | Straight line, arc, screw thread interpolation | point drilling loop | G81, G82 | |||
Cutter compensation: | Length of the compansation、nose of tool compensation | cycle of cutting thread | G92 | |||
Cutter compensation input: | Try to cut measuring input mode | Boring loop | G85, G86, G89 | |||
Spindle function: | gear、Double analog control、Rigid tapping | Tapping loop | G74, G84 | |||
Handwheel function: | panel、handheld | Cycle of rough cut at end face: | G22, G800 | |||
handwheel processing: | The handwheel processing function | Cycle of closed cut | G52 | |||
Screen protection: | The screen protection function | Cycle of drill deep hole at end face | G31, G311 | |||
Communication function: | RS232、USB interface | program loop | G15/16 | |||
Compensation function: | cutter, clearance, screw, radius compensation | local coordinate system: | G76 | |||
Edit program: | relative/absolute programming, hybird programming | check skip | G22,G800 | |||
Preread function: | Preread 10,000 short straight lines | polar programming | G20/21 | |||
limit position function | hard limit, soft limit | program mode | G90/91 | |||
Password protection: | Multilevel password protection | processing plane | G17, G18, G19 | |||
Input/output: | I/O 24*24 | workpiece coordinate system: | G54~G59 | |||
PLC programme: | All open PLC design | tool length compensation | G43, G44, G49 | |||
Acceleration and deceleration control: | Straight line、Index | tool radius compensation | G45~G48 | |||
Number of encoder: | any setting | C tool radius compensation | G40,G41,G42 | |||
User macro program: | Have | Accurate locating/continuous path process: | G60/G64 | |||
Electrical gear function: | Have | returns the starting point | G26, G261~G264 | |||
Application: | Lathe, turning, special machine | returns the fixed point | G25, G61, G60 | |||
returns the reference point | G28, G281~G284 | |||||
Backing to the fixed point: | G40 | |||||
Auxiliary function: | S、M、T | |||||
Product features
Never Crush the machine, the system with memorial function (Abosolute feature)
Needn't install hard limit with this 3 axis control wood drilling and milling machine and back to the zero point (Abosolute
feature)
Adapt bus modbus technology, ARM + DSP + FPGA technology
USB and RS232 port, DNC function of USB (NEW)
Network remote technology and could diagnose the system online (NEW)
User's storage is 128M and could be infinite number of program (NEW)
Abosolute type of motor (17bits multi circle) controlling technology (NEW)
The most moving rapid speed is 300m/min, processing speed reaches 0.01 ~ 30m/min (NEW)
The cycle of interpolation is 2ms, controlling accuracy is 0.1um (NEW)
All closed-loop with grating ruler control and the accuracy is <2um (NEW)
Preread the short line program to satisfy with high speed engraving and cutting (NEW)
Needn't install hard limit with this 3 axis control wood drilling and milling machine and back to the zero point (Abosolute
feature)
Adapt bus modbus technology, ARM + DSP + FPGA technology
USB and RS232 port, DNC function of USB (NEW)
Network remote technology and could diagnose the system online (NEW)
User's storage is 128M and could be infinite number of program (NEW)
Abosolute type of motor (17bits multi circle) controlling technology (NEW)
The most moving rapid speed is 300m/min, processing speed reaches 0.01 ~ 30m/min (NEW)
The cycle of interpolation is 2ms, controlling accuracy is 0.1um (NEW)
All closed-loop with grating ruler control and the accuracy is <2um (NEW)
Preread the short line program to satisfy with high speed engraving and cutting (NEW)
