SMD Electrolytic Capacitor 35V 1000uF 108 Aluminum

SMD/CHIP Aluminum Electrolytic Capacitor 35V 1000uF

PRODUCT SPECIFICATIONS

Rated Voltage

35V.DC

Nominal Capacitance

1000uF 1000μF 108

1000MFD 1000MKF

Capacitance Tolerance

±20% at 20°C 120Hz

Dissipation Factor(MAX)

tanδ≤0.12 at 20°C 120Hz

Leakage Current(MAX)

I≤0.03CV 1Min C=Capacitance

I≤0.01CV 2Min V=Rated Voltage

Low Temperature Stability

Impedance Ratio(MAX)

Z(-25°C)/Z(20°C)=4 at 120Hz

Z(-40°C)/Z(20°C)=8 at 120Hz

Life Time

at 105ºC 2000 hours

Size

Dia 16×16.5mm
