pressure sensor liquid vacuum sensor analog output pressure transmitter manufacturer
- Category: >>>
- Supplier: Hangzhou Sinomeasure Automation Technology Co. Ltd.
Share on (1600518171490):
Product Overview
Description
Products Description
Pressure range | Pressure Type | Gauge pressure/Absolute pressure/ Sealed pressure |
Pressure range | 1-600Bar (optional) | |
Technical Index | Power supply | 24VDC 12VDC 12-36VDC |
Signal output | 4-20mA 0-20mA 1-5V 0-5V | |
Signal line specification | 2wire 2wire 3wire 3wire | |
Zero Drift | ±0.03%FS/°C | |
Accuracy | ±0.1%FS ±0.3%FS ±0.5%FS | |
Thermal Sensitivity Shift | ±0.03%FS/°C | |
Longterm Stability (1 Year) | ≤0.21%FS | |
Frequency Response (-3dB) | 5kHz~650kHz | |
Compensated Temperature | -10~70℃ | |
Working Temperature | -40~85℃ | |
Storage Temperature | -40~125℃ | |
Overload pressure | 200%FS | |
Protection Classification | IP65 | |
Body materials | 316 stainless steel (standard) | |
Transmission distance | ≤100m (No electromagnetic interference) | |
Pressure connection | G1/4, G1/2, 1/2NPT, 1/4NPT, M12*1.5, M20*1.5 etc. (optional) | |
Measure media | Gas, water, oil or other media can be compated with stainless | |
Accuracy | ±0.3%FS ±0.5%FS | |
Terminal Block Specifications | Hirschmann connector, aviation conncetor, direct lead |
Company Profile
FAQ
Q: Is there any stock?
A: Yes,we have materials in stock to help you to get the samples as soon as we can
Q: How to track my Order?
A: After shipped, we will email you the tracking number.You can check the shipping status of your order on the website.
Q: How about warranty ?
A: Warranty: 12 months, Lifetime maintenance
Q: How about after-sales service?
A : We are 24 hours online, if you have any problem,pls contact us directly.
Q: Any discount?
A : For bulk purchase or distribution agents, we will apply the best price for you,If we have any promotions, we will post in store and send you an email to inform you.
A: Yes,we have materials in stock to help you to get the samples as soon as we can
Q: How to track my Order?
A: After shipped, we will email you the tracking number.You can check the shipping status of your order on the website.
Q: How about warranty ?
A: Warranty: 12 months, Lifetime maintenance
Q: How about after-sales service?
A : We are 24 hours online, if you have any problem,pls contact us directly.
Q: Any discount?
A : For bulk purchase or distribution agents, we will apply the best price for you,If we have any promotions, we will post in store and send you an email to inform you.
