db15 d sub dsub connector 15 pin connector d sub d type female socket dual row solder ITT Cannon DB 15P A191 K87 121073 2291 D
db15 d sub dsub connector 15 pin connector d-sub d type female socket dual row solder ITT Cannon DB-15P-A191-K87 121073-2291 D
db15 d sub dsub connector 15 pin connector d-sub d type female socket dual row solder ITT Cannon DB-15P-A191-K87 121073-2291 D

db15 d sub dsub connector 15 pin connector d sub d type female socket dual row solder ITT Cannon DB 15P A191 K87 121073 2291 D

Share on (1600519954925):


Price:

Quantity:


Product Overview

Description





Contact Resistance:
20M Ω Max
Insulation Resistance:
1000M Ω Min
Contact Material:
Brass (C3604)
Insulation Material:
Polyester
Contact Plating:
Gold Plated
Material Flammability Rating:
94-V0
Contact Plating Thickness:
G0 to G6
Operating Temperature:
-55°C to +105°C
Current Rating:
3.0 AMP
Insulator Color:
Custom
No. of Row:
2
Mounting Type:
Straight
No. of Positions:
15P
Termination:
Solder
Pitch:
1.385mm
Packing:
Original Packing
Row Spacing:
-
Certificate:
ROHS,REACH,ISO9001/14001
Manufacturer Standard Lead Time:
1-3 Weeks
