engine brand | with new-brand |
canopy color | customers' requirement |
controller | deepsea/smartgen |
fuel tank | 8 hours working hours |
Diesel generator set specifications | Engine Specifications | Alternator Specifications | ||||||
Model | GF30WP | Engine brand | WEICHAI | Alternator brand | HENGTONGKEDIAN | |||
Prime Power | 37.5KVA/30KW | Engine Model | WP2.3D40E200 | Model: | HJI-30 | |||
Standby Power | 41.25KVA/33KW | Standby power(KW) | 33 | Rated Capacity (KW/KVA): | 30/37.5 | |||
Frequency: | 50Hz/60Hz | Prime power (KW) | 41.25 | Winding: | 100% Copper Wire | |||
Voltage: | 400V or customized | Governor | Electronic | Frequency: | 50Hz/60Hz | |||
Phase: | 3 | Cylinders/ Arrangement | 3/L | Speed: | 1500 RPM/ 1800RPM | |||
P.F(COS¢): | 0.8 | Bore x stroke(mm*mm) | 105x 125 | Connecting Type: | 3 Phase and 4 Wires, "Y" /" Δ" type connecting | |||
Fuel: | Diesel | Consumption of fuel | 225G/KWH | Power Factor: | 0.8 | |||
Rated Current: | 1082.5A or customized | Lub.oil cap.(L) | 10 | Protection Grade: | IP23 | |||
Start Method: | 12/24V | displacement(L) | 4.33 | Exciter Type: | Brushless, self-exciting | |||
