Customized 2000W 1000W 12V 100A 24V 60A 36V 40A 48V 30A 60V 25A 72V 20A AC battery charger for Lead acid Lithium LifePO4 battery


AC Converter&Battery Charger
1. Three stage timer-based charging algorithm
2. Most suitable for fast battery charging
3. Operate with wider input voltage range
4. Compact design
5. High efficiency
6. Highly reliable MOSEFET base design
7. Smart fan control


Products Description














Specification
Input voltage
CSBXXHXX
184-286Vac full performance
90-184Vac automatically derates to 50% of current settings
CSBXXLXX
96-145Vac full performance
70-96Vac automatically derates to 50% of current settings
Frequemcy
40HZ to 70HZ
Nominal Input Current at Rated Output
＜9A
Voltage Measurement Accuracy
±8VAC
Frequency Measurement Accuracy
±1Hz
Output voltage
CSBXXXXX  XX:10: 1000W   20: 2000W  X: H/L ( Input voltage Type)XX: 12/24. 36/48,12,24,36,48( Battery Voltage Type)
CSB10X1224
CSB10X3648
CSB20XXX
Output current
75A/37.5A
25A/18.75A
120A 60A 40A 30A
Rated output current
Manual adjustable
Current accuracy
±6%of full rated output current@ 25℃, for target currents across the range from 10% rated output( for absorption exit criteria accuracy) to the current limit set point.
Load regulation
1.5%
Battery type selected
Four charging voltages can be adjusted manually
Parallel outputs
Maximum of two AC converter units connected in parallel
Efficiency
80%
Protection
Input over/under voltage protection
Reverse battery polarity protection
Output over voltager protection
Charger over temperature protection
BTS(Battery Temperature Sensing)
Dimension(DXWXH) mm
261.4*160*70 mm
307.4*180*82 mm
Unit Weight
2.65KG
4.0KG
Gross Weight
2.9KG
4.2kg
