Model | LCV300 | LCV500 | LCV1000 | ||
Rated Capacity | 300kg | 500kg | 1000kg | ||
Navigation Method | Laser Navigation | Laser Navigation | Laser Navigation | ||
Turning Radius | 506mm | 506mm | 506mm | ||
Dimension(L*W*H) | 880*620*305mm | 1080*720*305mm | 1280*820*410mm | ||
Angle Accuracy | ±1% | ±1% | ±1% | ||
Max. Traveling Speed(loaded/unloaded) | 0.7/1.0m/s | 0.7/1.0m/s | 0.7/1.0m/s | ||
Body Weight(without load) | 185kg | 210kg | 300kg | ||
Positioning Accuracy | ±10mm | ±10mm | ±10mm | ||
Max. Gradeability(loaded/unloaded) | <5% | <5% | <5% | ||
Communication Methord | WIFI/5G | WIFI/5G | WIFI/5G | ||
Travel Direction | Two Way | Two Way | Two Way | ||
Full Charged&Discharged Cycles | 1500 Times | 1500 Times | 1500 Times | ||
Battery Capacity | 48V/30Ah | 48V/30Ah | 48V/30Ah | ||
Battery Type | LiFePO4 | LiFePO4 | LiFePO4 | ||
Charging Method | Manual/Automatic | Manual/Automatic | Manual/Automatic | ||
Charging/Working Time | 1/6 Hours | 1/6 Hours | 1/6 Hours | ||
Security | Laser Scan, Safety Contact Edge | ||||
