cij coding and marking series number qr code inkjet printer for electronics circuit boards pcb
- Category: >>>
- Supplier: Chengdu,Linservice,Industrial,Inkjet,Printing,Technology,Co.,Ltd.
Share on:
Product Overview
Description
Products Description
The cij inkjet printer is widely used in food, daily chemical, medicine, building materials, ultra-high-speed
assembly line and other industries. It can spray print variable information such as production date, shelf life, batch number, text, pattern, bar code and so on.
assembly line and other industries. It can spray print variable information such as production date, shelf life, batch number, text, pattern, bar code and so on.
Parameter specification | ||
Product Name | cij coding and marking series number qr code inkjet printer for electronics circuit boards pcb | |
MOQ | 1 | |
Number of rows | 1 to 3 lines | |
Maximum Speed (Ideal Point Distance) | 2.48 m/s 0.35 m/s | |
Maximum number of characters | 1680 per second | |
Character height range | 1.3-18 mm | |
Data length (number of characters) | 680 (7)×6 dot matrix) | |
Text input method | Full spelling input | |
Patterns input method | U-disc import | |
Character Control | 1、Left and right reverse printing 2、Adjustable printing height, width and delay 3、Fixed and variable text, uppercase and lowercase characters 5、Continuous Number 6、Flexible choice of date and time format and automatic date calculation 7、Character bolding up to 9 times 8、Batch number and counting function 9、Automatic shift, date and time format 10、Real-time clock function for printing to seconds 11、Timing data function 12、bar code | |
Type | Standard medium nozzle | |
Nozzle size | 60 micron | |
Nozzle material | gemstone | |
Length of conduit | 2m/4m optional | |
Nozzle positive pressure air line | Optional | |
Synchronizer | TTL level or collector open, 5V~24V | |
Product Detector | PNP or NPN collector open, 5V~24V | |
Warning device | External alarm, 24V | |
Communication | Rs232 interface for communication with computer or other control equipment | |
Ink Power | Built-in gear pump | |
Viscosity control | Automatic Viscosity Control | |
Clear nozzle | Clear automatic nozzle | |
Ink types | Butanone/Alcohol/Mixture | |
Control panel | QWERTY keyboard for standard PC | |
Protection Class | IP55 protection level | |
Box Material | Stainless steel material | |
Chassis dimensions | 580 mm×480 mm×325 mm | |
Weight | 32KG | |
Power | 53W | |
Operating temperature | Range 5-45 C (40-117) | |
Relative humidity | Range 10-90% [non-condensing] | |
Power requirements | Single-phase automatic range 90-130V/180-260V 50/60HZ 220V | |
Logistics Packaging Weight | 36kg | |
Logistics Packaging Size | 46.5cm×67.5cm×47cm | |
Company Profile
Located in Chengdu, Sichuan Province, China, the hometown of giant panda, Chengdu Linservice Industrial Inkjet Printing Technology Co., Ltd. has become a leader in the product identification industry with its strong technical strength, complete production equipment, strict quality testing, mature manufacturing.
As a professional inkjet printer product provider, it has professional technology and product resources and focuses on the product identification and safety of the enterprise. With more than nearly 20 years of service experience in the identification industry, it provides safe, assured and reliable product identification for all sectors of society, especially in the association and traceability application of industrial identification.
As a professional inkjet printer product provider, it has professional technology and product resources and focuses on the product identification and safety of the enterprise. With more than nearly 20 years of service experience in the identification industry, it provides safe, assured and reliable product identification for all sectors of society, especially in the association and traceability application of industrial identification.
Sample Room
Exhibition
Partner
Linservice has been a qualified supplier of P & G (China) Co., Ltd. for many years. The well-known customers include: P & G (China), Lafarge (China), Coca Cola, unified enterprise, Wuliangye Group, Jiannanchun Group, Luzhou Laojiao group, Tsingtao Beer Group, China Resources Lanjian group, Di'ao pharmaceutical group, China Biotechnology Group, Sichuan ChuanHua group, Lutianhua group, Sichuan Tianhua group, Zhongshun group, Chengdu new hope group, Sichuan Huiji food, Sichuan Liji group, Sichuan Guangle group, Sichuan coal group, Sichuan Tongwei group, Sichuan xingchuancheng group, Sichuan Jiahua group, Yasen building materials, Chongqing beer group, Chongqing Zongshen electric appliance group, Guizhou Hongfu group, Guizhou saide group, Guiyang snowflake beer, Guizhou Deliang prescription pharmaceutical, Yunnan Lancangjiang beer group, Kunming Jida Pharmaceutical Group, Kunming Jinxing Beer, There are hundreds of enterprises in Yunnan Wuliang zangquan, Gansu Jinhui liquor group, Gansu Duyiwei Co., Ltd., including food, beverage, pharmacy, building materials, cable, chemical industry, electronics, tobacco and other industries.
FAQ
1. How to guarantee quality?
From production to sale, the machine is checked at every step to ensure that the final equipment is in order.
2. Can you guarantee the safety in transit?
It can ensure the safety in transit. Our packing is very strict.3.Will you provide after-sale technical service?
We will provide 24 hours after-sales service, we will also have technical staff to answer your questions
4. Can I repair it if it breaks down?
Can repair
5. Where can these devices be used?
Our products cover printing and packaging, food and beverage, chemical building materials, pharmaceutical, tobacco, daily chemical, automotive and aerospace manufacturing and many other industries.
6. How do I know if your machine works well?
Before delivery, we have tested each machine and adjusted it to the best condition. If you have special production conditions, we will adjust to the corresponding state for you.
From production to sale, the machine is checked at every step to ensure that the final equipment is in order.
2. Can you guarantee the safety in transit?
It can ensure the safety in transit. Our packing is very strict.3.Will you provide after-sale technical service?
We will provide 24 hours after-sales service, we will also have technical staff to answer your questions
4. Can I repair it if it breaks down?
Can repair
5. Where can these devices be used?
Our products cover printing and packaging, food and beverage, chemical building materials, pharmaceutical, tobacco, daily chemical, automotive and aerospace manufacturing and many other industries.
6. How do I know if your machine works well?
Before delivery, we have tested each machine and adjusted it to the best condition. If you have special production conditions, we will adjust to the corresponding state for you.
