Product Description
Screen size: 21.5"
Resolution: 1920 (RGBW) * 1080[UHD]
Display size: 476.64 (horizontal) * 268.11 (vertical) mm
Visual size: 479.84 (horizontal) * 271.31 (vertical) mm
Brightness (cd/m2):350 (Typ.)
Best angle: full view
Visual angle: 89/89/89/89 (Min.) (CR = 10)
Pitch: 0.0825x0.2475mm
Color quantity: 16.7M, 72% (CIE1931)
Screen weight: 1.67Kgs (Typ.)
Refresh frequency: 60Hz
Signal system: 30 pins LVDS (2 CH, 8-bit), terminal
Supply voltage: 5.0V (Typ.)
Maximum rating: storage temperature: -20 ~ 60 degrees C operating temperature: 0 ~ 50 degrees C
Screen type: LCD module, a-Si TFT-LCD
Pixel configuration: RGBW vertical strip
Appearance size: 495.6 (horizontal) * 292.2 (vertical) * 11.1 (thick) mm
Surface treatment: Fog (Haze 1%), Hard, coating (3H)
Contrast: 1000: 1 (Typ.) [transmission]
Optical mode: TN, often black display, transmission type
Response speed: 13/5 (Typ.) (Tr/Td) MS
Backlight type: WLED, [17S4P], 30K hours, no drive
CPU: RK3188, quad-core, frequency 1.6GHz
Memory: 1 / 2G (optional)
Built-in memory: EMMC FLASH 8G (optional)
Built-in ROM: 2KB EEPROM
Decoding resolution: up to 1080P
Operating system: Android 4.4 above
Play mode: support for the cycle, timing, spots and other playback modes
Network support: 3G, Ethernet, WiFi support, wireless peripherals expansion
Video playback: support wmv, avi, flv, rm, rmvb, mpeg, ts, mp4 and so on
Picture format: support BMP, JPEG, PNG, GIF
USB2.0 interface: 3 USB HOST, 3 USB socket
Serial port: 3 serial socket
TVIn: CVBS input 2, support N, P standard
GPS: built-in GPS (optional)
WIFI, BT: built-in WIFI, BT (optional)
Ethernet: 1, 10M / 100M adaptive Ethernet
Timing switch machine: support
Infrared touch |
Material: tempered glass
Glass thickness: 3mm, 4mm, 6mm
Surface abrasion strength: strong, determined by the glass surface
Transparency: ≥95%, up to 100% (no glass)
Homogeneity: good
|
Company Information
Welcome to Shenzhen P&Y Technology Co., Ltd
We are a professional manufacturer of Advertising display screen & android tv box with well-equipped testing equipment and strong technical force.With a wide range,good quality, reasonable prices, stylish designs and huge Tech team support,our products are extensively used in many industries.look forwarder to start cooperation with you!
Packaging & Shipping
PACKAGE:
Standard export carton packing.
DELIVERY TIME:
3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
