Factory Price Semi automatic Dry Fluorescence Immunoassay Analyzer
- Category: Clinical Analytical Instruments >>>
- Supplier: Wuxi Opulen Technology Co. Ltd.
Share on (1600523510051):
Product Overview
Description
Product Description
TFL-1600 Dry Type Fluorescence Immunoassay Analyzer
Working Principle : During the detection, the detection sample that has been thoroughly mixed with the buffer is added to the sample well of the reagent card, and the analyte in the sample forms an immune complex during the chromatography process. When the incubation is complete and the test is started, the light source of the instrument illuminates the detection area and the quality control area of the reagent card, and excites the attached fluorescent substance to emit fluorescence, and the fluorescence is collected and converted into an electrical signal. The strength of the electrical signal is strictly related to the number of fluorescent molecules. The concentration of the analyte in the sample can be analyzed by the strength and the ratio of the electrical signals of the detection line and the quality control line.
Working Condition
Power requirements: AC220V±10%, 50Hz±1Hz, 130VA Max;
Indoor use, the altitude is below 2000m;
Ambient temperature: 10℃～30℃;
Away from strong electromagnetic field interference sources;
Avoid direct sunlight;
Have good grounding;
Relative humidity: ≤80%;
Atmospheric pressure: 86kPa～106kPa;
Have good grounding;
Relative humidity: ≤80%;
Atmospheric pressure: 86kPa～106kPa;
Specification
Display | 10.1" screen |
Interface Type | USB port, Serial port, 4G, Bluetooth, Ethernet port, WiFi (Does not support users to transmit data via Bluetooth, Ethernet and WIFI) |
Excitation Light Source | LED |
Working Light Source | 610±10nm |
Detection Channel Number | 8 |
Working Feature | Semi-Automatic (Manual sample loading, automatic card feeding, incubation, testing, and card discarding operations) |
Data Storage | Above 500 000 group |
In-built temperature incubation | |
In-built thermal printer | |
Weight | 8kg |
Dimension | 292mm*290mm*311mm |
