RTK station GNSS receiver

Product Overview

Description

GNSS Receiver(Geodesic Receiver)
M65 RTK
The M65 is a high-end GNSS receiver, a new generation
of measurement engine, built-in 4G module, all-network
link, and multi-protocol radio, using a new appearance
design, magnesium alloy structure, Linux operating
system, is an extreme, intelligent, lightweight survey
GNSS receiver.

dicator light
Satellite light
Positioning status indicator
Bluetoothlight
BT connection status indicator
Data link light
Differential data link indicator
Mobile network indicato
Mobile network status indicator
Battery
Specification
7.4V,9750mAh
Endurance
>15hour (under typical power consumption)
Environmental
features
Working temperature
-20℃~+70℃
Storage temperature
-40℃~+85℃
Shock
resistance
2mdrop with pole at normal temperature
Protection rating
IP67
Physical
features
material
Magnesium alloy shell+ABS/PCPlastic lid
Dimension
156mm*156mm*102mm
Weight
1.4kg
Accessories
M65Host
1Set
Radio antenna
1PCS
Data cable with 7 core
1PCS
Power adapter
1PCS
