Electrical Copper Busduct Low Voltage Busbar Busway System
- Category: >>>
- Supplier: Chongqing Tianbao Conductor Busbar Electrical Co. Ltd.
Share on (1600523584952):
Product Overview
Description
Product Description
CM compact busway is used in AC 3 phase 4 wires or 3 phases 5 wires distribution system, rated current is 250A~5000A,as a scheme of low cost and high efficiency for industrial factory, hospital, high building and those environment with high-tech, to achieve good performance
Compact busbar trunking system
Specification
-Current Rating: 400 A to 6300 A(Copper) or 100A to 4000A(AL)
-Current Rating: 400 A to 6300 A(Copper) or 100A to 4000A(AL)
- Ingress protection: IP54 or IP65
- Insulation curent rating: [upto 1000 A]
- Standard lengths: 4m/3m/2m/1m
- System Voltage: AC380 /690V
- Conductor material: High conductivity Copper or AL
- Halogen free, fire retardant Class-B-Epoxy insulation
- Tap - off units are suitable for MCCBs or SDFs or MCBs
- Insulation curent rating: [upto 1000 A]
- Standard lengths: 4m/3m/2m/1m
- System Voltage: AC380 /690V
- Conductor material: High conductivity Copper or AL
- Halogen free, fire retardant Class-B-Epoxy insulation
- Tap - off units are suitable for MCCBs or SDFs or MCBs
Product application
Packing & Delivery
Packing :standard wooden case or according to customer requirements
