Co2 Supercritical Extraction For Oil Extraction Machine
- Category: >>>
- Supplier: Liaoyang Xianglong Pharmaceutical Machinery Co. Ltd.
Share on (1600523651781):
Product Overview
Description
Product Description
Supercritical carbon dioxide extraction equipment
The technology of SFE(Supercritical Fluid Extraction) is a new subject from Modern Chemicals Industries, which is one of the advanced Separation Technology. As for SCF(Supercritical Fluid), it is was that fluid on Critical Point(Pc, Tc) under
Thermodynamic State, the Critical Point is the state point when interface of Gas and Liquid disappear, which process very novel physical& chemical characters. It density degree close to liquid, viscosity degree close to gas, but bigger diffusion coefficient &dielectric constant, smaller viscosity etc. these characters have contributed to good separation effects. So the SFE is mainly about Separation, the solution will touch with extracted materials under High Pressure& Suitable Temperature, the Solutes would be diffused into the solution, then change the operation Conditions, to make the Solutes separate out.
Thermodynamic State, the Critical Point is the state point when interface of Gas and Liquid disappear, which process very novel physical& chemical characters. It density degree close to liquid, viscosity degree close to gas, but bigger diffusion coefficient &dielectric constant, smaller viscosity etc. these characters have contributed to good separation effects. So the SFE is mainly about Separation, the solution will touch with extracted materials under High Pressure& Suitable Temperature, the Solutes would be diffused into the solution, then change the operation Conditions, to make the Solutes separate out.
Details Images
Advantage
1.Easy to operate and adjust;
2.Well selectivity. Can extract out requested component according to control pressure and temperature.
3.Low operating temperature. Operation often happen under room temperature, which is much better for Heat-sensitive Materials. Because during extraction process, it has avoid “when oxygen oxygenation” and “when light reaction”, product can keep its natural tastes.
4.Finish within one step, CO2 won’t be left on the products.
5.CO2 is one kind gas of non-poisonous, tasteless, inflammable, cheap and can be cycle use.
Quick extraction speed.
Quick extraction speed.
Technical specifications
Technical parameters | ||
Model | SFE-50 | |
extract pressure | 50MPa | |
Single extract cylinder volume | 1L | |
Extraction temperature | Room temp – 75℃ | |
flow | 0-50L/h(adjustable) | |
Kettle material | 1Cr18Ni9Ti | |
Separation kettle volume | 600ml * 2sets | |
Separation kettle pressure | 30MPa | |
CO2 store tank volume | 3L | |
CO2 store tank pressure | 16MPa | |
Weight | 800KG(Approximate) | |
Related products
Our Company
FAQ
Q1: Are you a manufacturer or a trader?
A: As a professional manufacturer, we have our own factory, and if a customer has reasonable demand, out machine can be customized.
Q2: How do you ensure the machine quality?
A: As a professional manufacturer of pharmaceutical devices for more than 15years, with strict management, advanced
processing technologies and professional workers, we are confident for our machines quality. And before any
machine is delivered, will be carefully tested.
Q3: How can I trust you for the first cooperation?
A: Since our company was founded, we have registered in China Industry and Commerce Bureau. We passed the SGS &
ISO certification, and we are a senior member in Alibaba international platform (more than 12years). For the first deal between us, the Alibaba's Trade Assurance service can be used, which will fairly protect your rights and money throughout the transaction process.
Q4: How do I place an order, and how is it completed?
A: Under the condition that the buyer is satisfied with the quotation and pre-sales service:
1. Both of parties sign on a contract, and then the seller prepare the PI.
2. The buyer arranges the down payment.
3. The seller prepares the machines.
4. After the machine is completed, have the test & trial run.
5. Before the delivery, if the buyer requires, have the necessary inspecting.
6. As per the contract/ PI amount, the buyer balances the payment.
7. The machine is going to be shipped.
8. After the machine is received, the seller provide the buyer guidance for the installation and the debugging.
A: As a professional manufacturer, we have our own factory, and if a customer has reasonable demand, out machine can be customized.
Q2: How do you ensure the machine quality?
A: As a professional manufacturer of pharmaceutical devices for more than 15years, with strict management, advanced
processing technologies and professional workers, we are confident for our machines quality. And before any
machine is delivered, will be carefully tested.
Q3: How can I trust you for the first cooperation?
A: Since our company was founded, we have registered in China Industry and Commerce Bureau. We passed the SGS &
ISO certification, and we are a senior member in Alibaba international platform (more than 12years). For the first deal between us, the Alibaba's Trade Assurance service can be used, which will fairly protect your rights and money throughout the transaction process.
Q4: How do I place an order, and how is it completed?
A: Under the condition that the buyer is satisfied with the quotation and pre-sales service:
1. Both of parties sign on a contract, and then the seller prepare the PI.
2. The buyer arranges the down payment.
3. The seller prepares the machines.
4. After the machine is completed, have the test & trial run.
5. Before the delivery, if the buyer requires, have the necessary inspecting.
6. As per the contract/ PI amount, the buyer balances the payment.
7. The machine is going to be shipped.
8. After the machine is received, the seller provide the buyer guidance for the installation and the debugging.
