Customized Mini Concrete Mixer Truck For Sale Concrete Mixer Dongfeng Concrete Mixer Truck Plant
- Category: >>>
- Supplier: Zhengzhou,Hengyou,Machinery,Manufacturing,Co.,Ltd.
Share on:
Product Overview
Description
Products Description
Features:
Mixing capacity: 2-10m3/batch
Mixing mechanism: the free mechanism, stirring according to the rotating movement of the mixing drum
Low mobility. The machine is usually fixed in place or pulled at a close distance.
Specialized for mixing slurry, mortar and flexible concrete. Combined with trucks to transport concrete over long
Feeding: using an excavator
Discharding: concrete mixture is discharged by reversing the mixing tank
Mixing mechanism: the free mechanism, stirring according to the rotating movement of the mixing drum
Low mobility. The machine is usually fixed in place or pulled at a close distance.
Specialized for mixing slurry, mortar and flexible concrete. Combined with trucks to transport concrete over long
Feeding: using an excavator
Discharding: concrete mixture is discharged by reversing the mixing tank
Type | 2m³ | 3m³ | 4m³ | 5m³ | 6m³ | 7m³ | 8m³ | 9m³ | 10m³ |
Geometric Volume | 3.6m³ | 5.2m³ | 6.1m³ | 8.5m³ | 9.6m³ | 10.2m³ | 11.8m³ | 13.2m³ | 15m³ |
Diameter of Drum | 1.6M | 1.8M | 1.8M | 2.05M | 2.05M | 2.15M | 2.2M | 2.3M | 2.3M |
Angle of Inclination | 13° | 15° | 15° | 14° | 14° | 16° | 16° | 14° | 14° |
Overall Size | 3750*1600*1810 | 4220*1800*2160 | 4610*1800*2215 | 4690*2050*2320 | 5100*2050*2432 | 5180*2150*2510 | 5374*2200*2573 | 5640*2300*2687 | 6120*2300*2742 |
Size of installing base | 760*2750 | 800*3300 | 800*3600 | 800*3900 | 800*4200 | 800*4200 | 860*4530 | 860*4900 | 860*5300 |
Rotation Speed | 0-10r/min | 0-10r/min | 0-10r/min | 0-10r/min | 0-10r/min | 0-10r/min | 0-10r/min | 0-14r/min | 0-14r/min |
Hydraulic Oil cooler | 16L | 16L | 16L | 16L | 18L | 18L | 18L | 20L | 20L |
Total Weight | 1200KG | 1400KG | 1500KG | 2280KG | 2330KG | 2450KG | 2670KG | 2980KG | 3210KG |
construction scene
workshop
Customer feedback
Company Profile
FAQ
Q1:Does the Concrete Mixer Truck Price by sea or land? Which port? |
A1: Our shipments are generally shipped by sea, which has strong carrying capacity and cheaper freight, and the seaborne is more tolerant of the category of goods, and the basic requirements can be met. We generally use Tianjin and Qingdao ports within China. |
Q2:How is your service in Volumetric Concrete Mixer Truck? |
A2:24 hours on line service,support Chinese,English and French techinical guidance. |
Q3:How you Small Concrete Mixer Truck Price In India Packing&delivery？ |
A3:Standard export wooden box,protect the machine from damage.If your order is big and we have no stock,we promise to delivery within 7 to 12 days. |
