80A 230V Din rail adjustable over voltage and under voltage protective device protector relay with over current protection

Product Overview

Description

80A 230V Din rail adjustable over voltage and under voltage protective device protector relay with over current protection



Function:

1. Under voltage protection 210V-140V (adjustable) (default: 160V)

2. Over voltage proteciton 230V-300V (adjustable) (default: 280V)

3. Over current protection 1A-80A (adjustable) (default: 20A)

4. Reconnect time (delay on time): 1s-300s (default: 5s)

5. Voltage meter

6. Ammeter

Rated voltage: 220V; Frequency: 50Hz/60HZ

Over current protection: 1A-80A (adjustable) (default: 20A)

Under-voltage action switch-off value: 210V-145V (adjustable) (default: 160V)

Over-voltage action switch-off value: 230V-300V (adjustable) (default: 280V)

Reconnect time (delay on time): 1s-300s (default: 5s)

Error in real-time current, voltage : ≤5%
