Product Overview

Description



Product Description




Specification


Measure
-ment
 Range
Resolution
Accuracy
Voltage/Current/Frequency
Vrms(AC+DC)
1 ~ 1000
Vrms
0.1Vrms
±0.5% of nominal voltage
Vpk
1 ~ 1400
Vpk
0.1Vpk
±0.5% of nominal voltage
V(Crest Factor)
1.0 ~ >2.8
0.01
±5%
Arms (AC)
10mV/A
0~ 100A
0.1A
±0.5% ± 0.2A
1mV/A
1~1000A
0.1A
±0.5% ± 0.2A
50mV(65mV)
/1000A
15~ 5000
A
1A
±1% ± 2A
A(Crest
Factor)
1 ~ 10
0.01
±5%
Frequency
42.5 ~ 57.5Hz (50Hz nominal)
0.01Hz
±0.01Hz
Frequency
51 ~ 69Hz (60Hz nominal)
0.01Hz
±0.01Hz
385~414Hz (400Hz nominal)
0.01Hz
±0.01Hz
Dips & Swells
Vrms1/2
0 ~ 200% of nominal voltage
0.1Vrms
±1%
Arms1/2
1 ~ 3000A
1A
±1% ±2A
Duration
hour-minute-second-
micro-second
0.5 cycle
1 cycle
Harmonic(IEC61000-4-7)
Harmonic Number
1 ~ 50
Harmonic Voltage %f
0.0 ~ 100.0%
0.10%
±0.1% ± nx0.1%
Harmonic Current %f
0.0 ~ 100.0%
0.10%
±0.1% ± nx0.1%
THD
0.0 ~ 100.0%
0.10%
±2.5%
Phase
-360° ~ 0°
1°
± nx1.5°
Power and Energy
Active Power/Apparent Power/Reactive Power
1.0 ~ 20.00MW
0.1kW
±1.5±10 digits
KWh
0.00kWh ~ 200
GWh
10Wh
±1.5±10 digits
Power Factor
0 ~ 1
0.01
±0.03
Flicker (IEC61000-4-15)
Pst(1min),
Pst,Plt,PF5
0.00 ~ 20.00
0.01
±5%
Unbalance
Voltage
0.0 ~ 5.0%
0.10%
±0.5%
Current
0.0 ~ 20.0%
0.10%
±1%
Voltage Phase
-360° ~ 0°
1°
±2digits
Current Phase
-360° ~ 0°
1°
 ±5digits
Voltage Transient
Vpk
±6000Vpk
1V
±15%
Vrms
10 ~ 1000
Vrms
1V
±2.5%
Min. Test Time
50us
Inrush Current
Arms
0~3000Arms
0.1
±1% ± 5digits
Inrush Duration
6s ~ 32min
selectable
10ms
±20ms
Logger
Recording
user-defined parameters for 4 phases at the same time
Memory
Data stored in Micro SD card, 8GB
Duration Time
2 hrs to 1 year, depends on the recording items and time interval
Interval
1s to 1 hrs
Monitor
Support EN50160 in default or user-defined standard
Channel
(Voltage/Current)
4/4
Voltage Range
1-1000Vrms, 6000V transient voltage
Current Range
depends on supplied current clamp
Micro SD card(bulid-in)
8GB
Battery
NI-MH, 3800Ah/>7h
interface
USB Host, LAN
Screen
5.6' TFT LCD with resolution320*240(SA2100)
Language
10-Chinese, English, French, German, Korean, Polish, Portuguese , Spanish, Turkish, Russian
Dimension/Weight
262*173*66mm/1.6kg
Wire Combinatios
1Ø+NEUTRAL,1Ø SPLIT PHASE,1Ø IT NO NEUTRAL,3Ø WYE, 3Ø DELTA, 3Ø IT, 3Ø HIGH LEG, 3Ø OPEN LEG, 2-ELEMENT, 2 1/2-ELEMENT
Electrical Safety
IEC61010-1 ,Safety Degree: 600V CAT IV 1000V CAT III


Packing & Delivery




Company Profile




FAQ


Q: What is the IEC61000-4-30 standard for power quality analyzer?
A: IEC61000-4-30 published by International Electrotechnical Commission (IEC) is an international standard that specify how power quality instruments should make measurements. Also it defines the exact measurement algorithms methods for power quality parameters such as power quality voltage, flicker, unbalance, harmonic, etc. Currently the latest version of the standard is IEC61000-4-30, Edition 3 which was published in 2015.
There are two classes defined in this standard-Class A and Class S, Suin SA2100 power quality analyzer is classified to Class S instrument, of which accuracy and performance requirements are not as strict as Class A.

Q: Does standard SA2100 include current clamps? Is the current clamp can support DC measurement?
A: Usually the standard quotation of SA2100 contains 4pcs rogowski coils PY-3000A. To meet different measurement needs, additional 5 types current transformer clamps-ST08-5A, CTC0080-50A, CTC0130-100A, CTC1535-1000A, ETCR035AD-1000A and 3 types rogowski coils-SY-1500A, PY-5000A and SY-6000A are supplied as option for user selection. While ETCR035AD-1000A can support AC/DC measurement, other types are only available for AC measurement.
