Product Overview
Description
Product Description
1.Top Lid：Position of Monitor (10kg MAX)
2.O2 Flush：High Oxygen Flow (25-75L/min)
3.Accurate Flowmeter：Built-in Pressure Stabilizer for steady Oxygen Supply
4.Anesthesia Vaporizer：Accurate Pressure, Flow and Temperature CompensationHigh Capacity (300mL)，Maintenance Free
5.Highly Integrated Breathing Circuit
Prevent Air Leakage and Reduce Waste of Oxygen andAnesthetic Drugs.
Prevent Air Leakage and Reduce Waste of Oxygen andAnesthetic Drugs.
APL Valve(2-70cmH2O)
Precise Airway Pressure Control Easy to Adjust
ACGO Switch-off Valve
Open and Close Breathing Circuit with a SwitchReduce Risk of Leakage and Loop Pollution
Breathing Bag Connector
0 ~90 Degree Adjustable Rcbrcathing Bag Conncctor, which Caterto Doctor's Habits
Leakage Test
For Lcakagc Test and to Prevent Cross-infection Causedby Hand Blocking Testing
CO2 Absorbing
Ergonomic Design with Handle for Single Hand DisassemblyEasy to Operatc
More Thorough in CO2 Absorption and more Economic
Sensitive Respiratory Valve Diaphragm
Ceramic Material Breathing Gas Valve Sheet, Sensitive in Feedback,More Suitable for Low Flow Anesthesia
Precise Airway Pressure Control Easy to Adjust
ACGO Switch-off Valve
Open and Close Breathing Circuit with a SwitchReduce Risk of Leakage and Loop Pollution
Breathing Bag Connector
0 ~90 Degree Adjustable Rcbrcathing Bag Conncctor, which Caterto Doctor's Habits
Leakage Test
For Lcakagc Test and to Prevent Cross-infection Causedby Hand Blocking Testing
CO2 Absorbing
Ergonomic Design with Handle for Single Hand DisassemblyEasy to Operatc
More Thorough in CO2 Absorption and more Economic
Sensitive Respiratory Valve Diaphragm
Ceramic Material Breathing Gas Valve Sheet, Sensitive in Feedback,More Suitable for Low Flow Anesthesia
Applicability: 1kg to 100kg Animal
Operation Mode: Semi-closed. Open Breathing Circuit for Option
Machine with Trolly: 60*60*130(cm)
Main Machine: 43*23*45(cm)
Flow Range: 0-4L/min
Plimit(APL): 0.2-7.0Kpa
O2 Flush: 25L/min-75L/min
Ventilation Modes: Autonomous Breathing , Manual
Tidal Volume: Autonomous
Breathing: According to the Strength of Animal Intuitive Respiration
Controlled Manually: 10m1-2000ml
CO2 Absorber: 1.2L, Circulatory Anesthesia is Available
Vaporizer: Sensitive Flow,Pressure and Temperature Compensation
High Quality Materials for Superb Performance,Especially at Low Flow
Isoflurane, Sevofluranc,Enflurane, Halothane
Tec 7 Selectatec & Tec 3 Cagemount Mount
Specification
item | value |
Place of Origin | China |
Model Number | Vam-100 |
Properties | Diagnosis & Injection |
Applicability | 1kg to 100kg Animal |
Operation Mode | Semi-closed. Open Breathing Circuit for Option |
Machine with Trolly | 60*60*130(cm) |
Main Machine | 43*23*45(cm) |
Flow Range | 0-4L/min |
Plimit(APL) | 0.2-7.0Kpa |
O2 Flush | 25L/min-75L/min |
Ventilation Modes | Autonomous Breathing , Manual |
Tidal Volume | Autonomous |
Breathing | According to the Strength of Animal Intuitive Respiration |
