Item | Data |
Type | 4-stroke gasoline OHV |
Cooling System | Forced air |
Cylinder Arrangement | Inclined, single cylinder |
Displacement | 80cm3 |
Bore×Stroke | 48.6mm×43.0mm (1.91 in×1.69 in) |
Operation Hours | 3.5Hr@rated load |
8Hr@1/4 rated load | |
Fuel | Unleaded gasoline |
Fuel Tank Capacity | 4.2L (1.11 US gal) |
Engine Oil Capacity | 0.35L (0.37 US qt) |
Ignition System | CDI |
Starting System | Recoil start/Electric start |
Noise power Level(Lwa) | 61dBA-73dBA(Zero load to full load) @ 7M |
Output Waveform | Pure-Sine Wave, THD <3% |
Rated Voltage | 100/240V |
Rated Frequency | 60/50Hz |
Rated Current | 15/7.8A |
Rated Output | 1.8kVA |
Maximum Output | 2.1kVA |
Safety Device Type | Electronic |
Rated Voltage | 12V |
Rated Current | 8A |
USB | 5V/2A/1A |
Safety Device Type | DC Protector |
