120hp farm tractor mower tractor other agricultural machinery & equipments tractors
- Category: >>>
- Supplier: Taian Taishan Guotai Tractor Manufacturing Co. Ltd.
Share on (1600525445938):
Product Overview
Description
compact tractor 4wd Farm Wheel Tractors 120 HP Wheel Tractor 4wd Wheel Tractor
Product Description
Specification
Model | TAISHAN-1204 |
Drive type | 4X4 Four-Wheel Drive |
Dimension of The Tractor | |
The whole machine size mm | 4300*2350*2960 |
Min. Operation mass (kg): | 3860 |
Wheel base mm | 2200 |
Minimum ground clearance (mm) | 365 |
Front/ Rear wheel tread | 1650-1950/1620-2020 |
Tyre size(front/rear) | 11.2-24/16.9-34 |
Braking and steering | |
Braking system | Disc brake type |
Steering type | Hydraulic steering |
Working device | |
Three-point-linkage: | Yes |
PTO/PTO Speed | 540/760, 760/850, 540/1000, 760/1000 |
(610mm) kn/Lifting Capacity | ≧21.3 |
Tillage depth adjustment | 15.9 |
Hydraulic system | |
Hydraulic output valve | 2 groups |
Transmission system | |
Clutch | dry type, double action |
(F+R) No. Of gears | 16F+8R |
Shift method | 4*2*(2+1) |
Max. speed | 34.85km/h |
Gear Position | Right-hand side |
Engine | |
Engine Type | QUANCHAI，Emission Stage II. |
( L ) Displacement | 4.578 |
Fuel tank capacity (L) | 90+60/100+85 |
( g/kw.h) Fuel consumption @ nominal power | ≤235 |
Air intake type | Turbocharging- Aspirated |
Air Filter | Oil bath |
Diesel Engine Specification | |
Number of cylinders | In-line, vertical, water cooled, four-stroke |
Bore(mm) | Direct-Injection |
Stroke(mm) | 4 |
Total displacement(L) | 108 |
Compression ratio | 125 |
Firing order | 4.578 |
Rated output(kW) | 17.5:1 |
Rated speed(r/min) | Electric starting |
Direction of rotation of crankshaft(view from flywheel end) | 66 |
Method of cooling | 2300 |
Method of lubrication | Counterclockwise |
Method of starting | Close, Forced water cooling |
Combination of pressure and splash | |
Electric |
Details Images
Company Profile
Implements
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Certifications
FAQ
1. Why choose us?
(1) Near 20 years Agricultural Machines Manufacturing Experience.
(2) Competitive price. Attractive design. Best performance. High quality.
(3) Full range products for choice.
(4) High reputation in More Countries.
(5) Experienced Service Team.
(6) Quick and Safe Delivery.
(1) Near 20 years Agricultural Machines Manufacturing Experience.
(2) Competitive price. Attractive design. Best performance. High quality.
(3) Full range products for choice.
(4) High reputation in More Countries.
(5) Experienced Service Team.
(6) Quick and Safe Delivery.
2. Are you tractor supplier or manufacturer?
We are tractor manufacturer. We can provide the complete tractor and spare part steady with competitive price, because we are the source.
3. Do you provide after-sales service?
During warranty period, free spare parts for quality-problem spare parts replacement.
4. what are your products?
The main products include large-size, middle-size and small-size Taishan brand 180-2404 series tractors, and also large and medium horse power, Taituo brand, 400-1804 series tractors, 450 CVT tractor, 2204 power shift tractor, 725 crawler tractor, as well as variable products for meeting the demands of different working areas and environments.
5. How about your packaging and shipping method?
Our product packaging details are metal frames, one 20'GP can hold 8 pieces; one 40'GP can hold 16 pieces(smaller than 50hp),Our mode of transportation is by sea, and the port is in Qingdao. we will Provide the best shipping solution, save the cost of logistics.
We are tractor manufacturer. We can provide the complete tractor and spare part steady with competitive price, because we are the source.
3. Do you provide after-sales service?
During warranty period, free spare parts for quality-problem spare parts replacement.
4. what are your products?
The main products include large-size, middle-size and small-size Taishan brand 180-2404 series tractors, and also large and medium horse power, Taituo brand, 400-1804 series tractors, 450 CVT tractor, 2204 power shift tractor, 725 crawler tractor, as well as variable products for meeting the demands of different working areas and environments.
5. How about your packaging and shipping method?
Our product packaging details are metal frames, one 20'GP can hold 8 pieces; one 40'GP can hold 16 pieces(smaller than 50hp),Our mode of transportation is by sea, and the port is in Qingdao. we will Provide the best shipping solution, save the cost of logistics.
