High Lift Large Flow Stainless Steel Deep Well Pump submersible water Centrifugal Pump
High Lift Large Flow Stainless Steel Deep Well Pump submersible water Centrifugal Pump
High Lift Large Flow Stainless Steel Deep Well Pump submersible water Centrifugal Pump
High Lift Large Flow Stainless Steel Deep Well Pump submersible water Centrifugal Pump
High Lift Large Flow Stainless Steel Deep Well Pump submersible water Centrifugal Pump
High Lift Large Flow Stainless Steel Deep Well Pump submersible water Centrifugal Pump
High Lift Large Flow Stainless Steel Deep Well Pump submersible water Centrifugal Pump

High Lift Large Flow Stainless Steel Deep Well Pump submersible water Centrifugal Pump

Share on (1600525752358):


Price:$315.00 - $320.00

Quantity:


Product Overview

Description











High Lift Large Flow Stainless Steel Deep Well Pump submersible water Centrifugal Pump


Material
SS304 or SS316L
Flow/H (Capacity)
0-100T/H (Customized)
Lift (Pressure)
0-8bar
Production Viscosity
1-50pas
Impeller type
Closed impeller/Open impeller
Working temperature
0-140 celsius degree
mechnical seal type
Sinlge mechanical seal
Double flushed mechanical seal
connection type
Clamp
Union
Flange
motor type
Normal
Ex-Proof
inverter
motor cover
Round/Square
Speed or Frequency
2900RPM/3400RPM 50HZ/60HZ


Sanitary Centrifugal pump Model Sheet
Model
FLOW(T/H)
Lift(M)
Speed(RPM)
Motor(KW)
RAY-1-14
1T
14
2900/3400
0.55
RAY-3-16
3T
16
2900/3400
0.75
RAY-3-20
3T
20
2900/3400
1.1
RAY-5-24
5T
24
2900/3400
1.5
RAY-3-30
3T
30
2900/3400
2.2
RAY-5-36
5T
36
2900/3400
2.2
RAY-10-24
10T
24
2900/3400
2.2
RAY-15-24
15T
24
2900/3400
3
RAY-10-36
10T
36
2900/3400
3
RAY-20-24
20T
24
2900/3400
4
RAY-15-36
15T
36
2900/3400
4
RAY-20-36
20T
36
2900/3400
5.5
RAY-30-36
30T
36
2900/3400
7.5
RAY-40-36
40T
36
2900/3400
11
We can customize the equipment according to customer requirements.


APPLICATION
LOW Viscosity Liquid as below:
Drugs: infusion, distilled water, high purity water, containing particles (3-6 mm) of traditional Chinese medicine liquid,
leaching liquid.
cosmetics: dyes, alcohol, essential oils.
beverage: alcohol, liquor, beer, malt juice, fermentation liquid, fruit juice and granular beverage.
dairy products: whey, cream, milk, liquid sugar
others: candy industry, baking industry, chemical industry, etc.














1.Q: Are you manufacturer or trading company?
A: RAYEN is a professional manufacturer.
2.Q: How could we confirm the details of the products?
A: RAYEN will provide the detail drawings for you to confirm.
3.Q: How long the warranty will be?
A: 1 Year warranty.
4.Q: Do you take L/C?
A: Yes, we accept Western Union, T/T and irrevocable L/C payable
5.Q: Can we become your distributor in our country?
A: Yes, we very welcome you! More details will be discussed if you are interested in being our agent.
