Pigtail or Free Space RED GREEN & BLUE adjustable white RGB Laser diode module
- Category: >>>
- Supplier: Elite Optoelectronics Co. Ltd.
Share on (1600525797714):
Product Overview
Description
Item | Specification |
Wavelength | 450nm & 520nm & 635nm, 462nm & 532nm & 640nm |
Output Power | 50,100,200,250,365,500,1000,2000,3000mW |
Spatial Mode | TEMoo, TEM01 |
M^2(Beam Quality) | 1.2 |
Beam Asymmetry | ≤1:1.2 |
Beam Divergence (full-angle) | <1.0mrad |
RMS Noise(20Hz to 20MHz) | <2.0% |
Peak-to-Peak Noise (20Hz to 20kHz) | <3.0% |
Long - term Power Stability | <5.0% |
Operating Voltage | 5.0VDC, 12.0VDC |
Polarization Ratio | Minimum 100:1,Vertical 50 |
Laser Drive Modes | CW, Analog Modulation, Digital Modulation, Computer Control |
CDRH Class | lllb ,VI |
ESD Protection | Level4 |
Power Consumption (W) | Typical5, Max.13 |
Laser Head Baseplate Temp | 50℃ |
Operating Temperature | -10℃ to 50℃ |
Storage Temperature | -20℃ to 60℃ |
Lifetime | >10,000hrs |
Description
Elite well-performed laser product—RGB Series Lase, which is extensively used in medical science, scientific research and artificial intelligence, such as medical imaging and instrumentation, optics test & inspection, hologram, AR, VR, and MR etc.
Features
1．High stability
2．High reliability
3．Controllable color
4．Controllable output power
5．Rich color changes
2．High reliability
3．Controllable color
4．Controllable output power
5．Rich color changes
1.High optical power and multi-color. 2 Free Space RGB or Fiber Coupled RGB optional
3.Long term stability(8hrs, ±3℃): ＜5.0% 4.High reliability
5.High power density 6.Uniform intensity distribution
Elite design and produce three-wavelength (or four-wavelength) combined lasers for customer. The RGB laser combines light from three different wavelengths - Red, Green, and Blue in nature - to generate output light that is white in appearance. Signal controller can produce rich color changes and have a wide range of uses.
FAQs
1. What's the way of shipping
Shipping via DHL, TNT, UPS, FedEx, and EMS.
2. What's the payment method?
Assurance payment on Alibaba
3. What's your MOQ?
1 Piece
4. What's the delivery time?
3 – 7 days for International Shipping
5. Can I customize the products based on my requirements?
Yes. We can design and produce lasers based on your special requirements.
6. Do you have any certifications for lasers?
Yes. All our lasers are certified with CE, RoHS, and IEC.
7. How long is the warranty period?
12 months.
Shipping via DHL, TNT, UPS, FedEx, and EMS.
2. What's the payment method?
Assurance payment on Alibaba
3. What's your MOQ?
1 Piece
4. What's the delivery time?
3 – 7 days for International Shipping
5. Can I customize the products based on my requirements?
Yes. We can design and produce lasers based on your special requirements.
6. Do you have any certifications for lasers?
Yes. All our lasers are certified with CE, RoHS, and IEC.
7. How long is the warranty period?
12 months.
