TZM 1250 X 4000 CNC Sheet Metal V Grooving Machine manufacture
- Category: >>>
- Supplier: Nantong Tengzhong Machinery Co. Ltd.
Share on (1600525990521):
Product Overview
Description
TZM 1250 X 4000 CNC Sheet Metal V Grooving Machine manufacture
Product description
| No. | Parameter | Unit | Model | |||||
| 2600*6000 | 2600*3200 | 3000*4000 | 2600*4000 | 1500*6000 | ||||
| 1 | Max.grooving width | mm | 2600 | 2600 | 3000 | 2600 | 1500 | |
| 2 | Max.grooving length | mm | 6000 | 3200 | 4000 | 4000 | 6000 | |
| 3 | Max.grooving thickness | mm | 4 | 4 | 4 | 4 | 4 | |
| 4 | Min.grooving thickness | mm | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | |
| 5 | Min.distance of the V from edge | mm | 8 | 8 | 8 | 8 | 8 | |
| 6 | Cutting speed | m/min | 45 | 45 | 45 | 45 | 45 | |
| 7 | Knife rest resolution (left and right) | mm | 0.001 | 0.001 | 0.001 | 0.001 | 0.001 | |
| 8 | Repeated positioning accuracy | mm | ±0.01 | ±0.01 | ±0.01 | ±0.01 | ±0.01 | |
| 9 | Knife rest resolution (up and down) | mm | 0.001 | 0.001 | 0.001 | 0.001 | 0.001 | |
| 10 | Repeated positioning accuracy | mm | ±0.01 | ±0.01 | ±0.01 | ±0.01 | ±0.01 | |
| 11 | Motor power | KW | 4.4 | 4.4 | 4.4 | 4.4 | 4.4 | |
| 12 | Pneumatic system pressure | MPa | 6-8 | 6-8 | 6-8 | 6-8 | 6-8 | |
| 13 | Overall dimensions | Length | mm | 7500 | 4700 | 5600 | 5600 | 7500 |
| Width | mm | 4000 | 4000 | 4500 | 4000 | 3500 | ||
| Height | mm | 2200 | 1980 | 2000 | 2000 | 2200 | ||
Company Information
hot product
FAQ
FAQ
Q: GUARANTEE PERIOD
A: Our product quality guarantee period is 12 months from B/L date. During guarantee period, we will provide spare parts without
any charge in case of quality discrepancy caused by us. If the malfunctions is caused by customers' incorrect operation, we will provide spare parts at cost price. We can also offer flexible extended warranties according to the actual situation.
Q: AFTER-SALES SERVICES
A: Our engineer can go to your factory for installation and show operation details on condition of you provide the round-trip air tickets, visa formalities, food and accommodation. In turn, your engineers can come to our factory for learning the installation, operation and maintenance for free.
Q: WHY CHOOSE US
A: 15 years machine exporting experience, give customer prompt after service feedback .
Self manufactured machine, quality strictly control. OEM service.
Q: What is your payment terms?
A:T/T,L/C, Western union and so on.
Q: How to operate your machine?
A:We will provide operational manual along with the machine, we can also send operation vedio for study. Face to face on line teaching is also available.
Q: How to choose a model?
A:Send us your plate material, max thickness, max width then we can give you suggestion.
Q: How long is your production time?
Normally standard model delivery time is 30 working days, for bigger model we will need 45 or 50 working days. For urgent order,we can finish at 15 days. Need to discuss by each order.
Q:Do you test your machine before delivery?
A: Every machine will need 24 hours running,then engineer debug before packing.
