item | value |
Warranty | 1 year |
Customized support | OEM, ODM |
Place of Origin | korea |
Brand Name | Rotork |
Model Number | Sptm-6V Sptm-65V |
Connection Type | 2 Wire |
Output Signal | 4 ~ 20 mA DC |
External Load Resistance | Rext ≤ (Vs-9) / 20 mA, 750 ohms @Vs = 24 V |
Supply Voltage | 9 ~ 28 V DC |
Conduit Entry | G 1/2 (except NEPSI) or 1/2 NPT(only NEPSI) |
Explosion Proof | Flameproof enclosure. Refer to "2.6 Certifications" |
Ambient Temperature | -40 ~ 85 °C (-40 ~ 185 °F) |
Linearity | ± 1 % F.S |
Painting | Polyester Powder Coating |
Weight | 2.8 kg (6.17 lb) |
