Low price automatic 25kg 50kg bag rotary 8 nozzles cement packer

Share on (1600526575768):


Price:

Quantity:


Product Overview

Description


Low price automatic 25kg 50kg cement bag counting packing machine





8S















1 Application:


Our packing machines are mainly used for filling cement into 25-50kg bags. In addition, they also can be used for filling other powdery and granular materials with good flow performance. Except manually bag inserting, all the other filling processes can be done by the packing machine automatically and continuously.





2 Brief of BHYW8S packin machine:


Model BHYW8S numerical control type rotary cement packing machine is the latest design of our company. The control system of the packing machine adopts technology of microcomputer and servo motor. It has main features of more accurate measuring accuracy, higher capacity, low failure rate and  environmental protection.








TECHNICAL DATA OF BHYW8S ROTARY CEMENT PACKAGING MACHINE






































































































































































No



Name



Unit



Data



1



Type







BHYW-8S



2



Qty of spouts



pc



8



3



Design capacity



t/h



120



4



Filling style







Side feeding



5



Discharging style







impeller



6



Weighing style







Microcomputer scale



7









Weighing precision









Single bag weight



kg



50



Single bag weight tolerance of 95% bags



kg



+0.4


-0.2



Total weight of successive 20 bags



kg



≥1000



8



Outer diameter of rotary bin



mm



Φ1560



9



Outer diameter of discharging spout



mm



φ2250



10



Distance from discharging spout to ground



mm



1300



11



Max rotary diameter



mm



φ2450



12



Control mode of complete machine







Mechanical, electric



13



Driver speed adjusting style







Frequency control



14



Range of speed adjusting



r/min



0-6



15



Rated rotate rate of the machine



r/min



5



16



Power supply







AC 380V 3P 50Hz



17



Fluctuation



%



+10  -15



18



Gross power of motors



kW



55.4



19



Dust collection airflow



m3/h



15000



20



Dust collection air pressure



Pa



-600



21



Rotary direction of the machine



Overhead view



Clockwise



22



Height of the machine



mm



5877



23



Total weight



kg



6000












2211










 FAQ


(1) What is the usage of the packing machine?


--This machine is mainly used for packing materials with good flow performance like cement, gypsum powder and other powder, particle size should be less than 1mm.





(2) What is the voltage required for the machines?


--Normal voltage 220V/50Hz / Single phase or 380V/50Hz / Three Phase. But it also can be made according to customers' demand, like 440V/60Hz / Three phase and so on.





(3) What about the packing?


--We pack machines in standard fumigated wooden cases.





(4) How long is the warranty for the machines?


--For non-human damage factor, within 12 months after commissioning or within 18 months from the date of B/L, whichever comes first.





(5) How should I do if meet some troubles while using?


--Don't worry about that. We are always be pleased to provide quality service to customers. We can show how to solve the problems by video and write detailed solutions to customers’ email. If the problems can’t be solved through these methods, we can send engineers to the work site of the customers to solve the problems.





(6) What's the payment mode?


--T/T, L/C





Pre-sale Service


1. Offering comprehensive technical and business consultation services;


2. Proposing the most suitable scheme and equipment for our customers;


3. Designing and fabricating targeted products according to the special requirements of clients.


After-sale Service


1. Highly inspecting equipments in every working procedure, quality comes first;


2. Fast & Safe delivery;


3. Assisting our customers for foundation construction of equipment;


4. Dispatching engineers to install and debug equipments if our customers required;


5. Training workers of customers for operating the machines on site;


6. Providing technical exchanging.
