Dual Energy X Ray Baggage Scanner High Resolution xray machine security

Product Overview

Description



The Dual Energy X Ray Baggage Scanner is a high-resolution scanner that detects hidden contraband in baggage, specifically explosives and nonmetalic weapons. It uses two distinct x-ray energies to identify objects of interest by comparing their density to the density of surrounding materials.

The Dual Energy X Ray Baggage Scanner can be easily integrated into existing airport security systems and supports a wide variety of bag types. In addition, it provides real-time feedback on the detection results so that security personnel can respond quickly and efficiently.

Monitor: High definition LCD, 17 or 19 inch

Image Enhancement: Make the edge of the object more clear

High Penetration Display: Brightening the contrast of the bright area to make the easy penetration area more clear Low Penetration Display: Darkening the contrast of the dark area to make the difficult penetration area more clear Thin Object Detection: Can press the corresponding function keys to detect the item which is too thin

Threat Image Projection (TIP):Inserting fictional, but realistic images of threat items into baggage during screening operation, for maintenance of vigilance, as well as training and assessment of image identification capability

Image Pull Back/ Pull Forward: Image pull forward or pull back processing

Image Storage: Real-time images storage and processing,up to 500,000 images stored automatically

Multi Color Display: 32bit real color display according to the materials

Ray Sensor: L-Shaped Array, 24 bit depth

Magnifier: Continuous zoom up observation

Border Warning: Can automatically identify and mark the border around the image of package

Image Returning: Original image can be restored

Brightening/Darkening: Brightening/Darkening the brightness of the image

Alarm: Sound and light alarm when meet the conditions,

Tunnel Size	500(W)* 300(H)mm	Operation temperature/Hu midity	0℃~45℃/20%~95% (non- condensing)
Conveyor Speed	0.22m/s	Storage Temperature/Hu midity	-20℃~60℃/20%~95% (non- condensing)
Conveyor Max Load	150kg	Operation Power	220VAC(±10%) 50±3HZ
Wire Resolution	Φ0.0787mm	Power Consumption	0.5KW(Max)
Penetration	>16 mm Steel	Noise	≤54dB
Film Safety	Guarantee ISO1600 Film	Power Supply	Ground wire is needed
X ray leakage	<0.1uGy/h(at a distance of
