Price:$125.00 - $170.00

Quantity:


Product Overview

Description









Products Description


Product name
Conference room movable wall
General Use
Commercial Furniture

Usage
Multi-function hall, banquet hall, conference room, exhibition hall, laboratory, convention centre, gymnasium, kindergarten, artgallery, restaurant, meeting room, office room;
Material
Acoustic material, MDF board, aluminum alloy;
Frame Material
Aluminum alloy
Thickness
100mm
Size
Customized size
Surface
Fabric


Surface Material
W.G
(kg/sq.m)
Soundproof Factor(db)
Partition Frame
Upper & Bottom Stretching Range(mm)
Thk
(mm)
Partition Load-bearing(KG)
MDF Board
(no melamine paper)
      38


44









Aluminum Alloy









30






100









2000
Plywood Board
38
MDF Board
38
Fireproof Board
40
46
Leather/Fabric Hard Cushion
40
46
Mgo Boar
52
48
Steel Board
54
50
Leather/Fabric Hard Cushion
(cover the edge)

54

50

130
Leather/Fabric Soft Cushion
(cover the edge)

54

50

130
Remarks:
Suggesting Height is less than 13m, be suitable for star class multi-function halls, Large conference centers, high class restaurants, banquet halls and so on.


Optional Material for Partition Wall Surface:
MDF Board
(no melamine paper)
The main components of MDF board are wood fiber, resin glue and so on, it is a kind of environment-friendly board which is formed after hot grinding, drying, sizing, paving, hot pressing, post treatment and sanding instead of log.
Plywood Board
Multilayer board is made of three or more layers of veneer or sheet wood and glue laminated byheat pressing the board.
MDF Board
MDF + melamine paper.
Fireproof Board
Add the fireproof board on MDF or Plywood board surface.
Leather/Fabric Hard Cushion
Stick the leather or fabric on the surface of MDF or Plywood baord.

Mgo Boar
Commonly known as magnesium oxide Board, is a kind of magnesium cementitious material with relatively stable performance. It is a new type of noncombustible decorative material  composed of medium-alkaline glass fiber mesh as reinforcement material and special material as filling material.
Steel Board
Stick the steel plate on the surface of MDF or Plywood baord.
Leather/Fabric Hard Cushion
(cover the edge)
Stick the leather or fabric on the surface of MDF or Plywood baord. Cover the edge of partition frame.
Leather/Fabric Soft Cushion
(cover the edge)
Stick the sponge on the surface of MDF or Plywood baord, and then cover the leather or fabric on sponge. Cover the edge of partition frame.


Movable Partition Wall Features:
1. Without ground track
2. Stable and safe
3. Sound insulation
4. Energy-saving insulation
5. High-effcient fire prevetion
6. Elegant appearance
7. Retractable and flexible
8. Easy storage
9. Wide spread use
Partition Walls Installation:
We will provide a complete and detailed installation plan and reference video for each project.


Details Images






Aluminum Track & Connector.
1. 6063-T6 high hardness aluminium;
2. Load-bearing: 300kg/m;
3. Aluminum wall thick is 4mm;
4. No jamming while wheels passing;
Partition's Wheels.
1. Import POM as plastic material;
2. 6002-2RS bearings;
3. High load-bearing;
4. Be used on the upper of partition;
Partition's Key.
1. Plastic and steel partition wall's key;
2. Function is to open and close the partitoin;


Partition Wall Parking Type:




Stell Structure Show:






Passing Door Sealing:




Horizontal Sealing:






Company Profile






Certifications




Packing&Delivery




FAQ


Q1. Do you accept customization?
Yes, our all partition walls are customized.

Q2. Need we provide the technical information or drawings?
Yes, we need, this is important.

Q3. What is your warranty time？
3 years gurantee, include all parts and defects.

Q4. Can I have a sample order?
Yes, we welcome sample order to test and check quality, but the sample is not free.

Q5. How do you ship the samples and how long does it take to arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q6. What about the leading time?
Generally speaking, the sample needs 3-5 days, production time needs 10-20 days.

Q7. Do you have any MOQ limit for partition wall order?
The MOQ is 10 square meters.

Q8. Is it OK to print my logo on packing?
Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q9.What is your terms of payment?
T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

Q10. How do you solve the installation problem?
We will provide targeted installation plan to let you know how to install;
If it is necessary, we will dispatch professional installor to your local install, but you side should be responsible for the cost of the air ticket and accommodation for the whole trip, and 120-200USD one person per day for instructions.
