Stainless Steel 304 Steam Jacked Kettle Boilers Jacketed Boiling Pan Tilting Cooking Pot
- Category: >>>
- Supplier: Henan Zgcm Machinery Co. ltd.
Share on (1600527110518):
Product Overview
Description
Electric heating jacketed pot parameters
model | volume（L） | Electric power/motor power(KW) | Diameter depth(mm) | Oil quantity (kg) | Weight (kg) | voltage（V ） | Dimensions（m) |
ZG50 | 50 | 10KW0.75KW | 600*420mm | 25 | 110 | 380V/220V | 1.2*0.75*1.2 |
ZG100 | 100 | 12KW0.75KW | 700*470mm | 33 | 125 | 380V/220V | 1.3*0.85*1.25 |
ZG200 | 200 | 16KW 1.5KW | 800*550mm | 43 | 150 | 380V | 1.45*0.95*1.35 |
ZG300 | 300 | 20KW 1.5KW | 900*600mm | 60 | 175 | 380V | 1.55*1.05*1.45 |
ZG400 | 400 | 24KW 1.5KW | 1000*680mm | 75 | 200 | 380V | 1.65*1.15*1.55 |
ZG500 | 500 | 27KW 2.2KW | 1100*720mm | 100 | 225 | 380V | 1.75*1.25*1.75 |
ZG600 | 600 | 30KW 2.2KW | 1200*780mm | 125 | 250 | 380V | 1.85*1.35*1.85 |
ZG800 | 800 | 36KW 2.2KW | 1300*870mm | 150 | 300 | 380V | 1.95*1.45*2 |
ZG1000 | 1000 | 40KW 2.2KW | 1400*950mm | 175 | 350 | 380V | 2.05*1.55*2.1 |
Application products
Jacketed pot is widely used in hot pot base, chili sauce, red oil cooking, jelly making, candy, lotus seed paste, red bean paste, jam, cakes, beverages, candied fruit, canned food, lotus seed paste, fruit paste, bean paste, jujube paste, sauces , Curry and other food processing and brewing, wine making, pharmaceutical and daily chemical industries, as material melting, disinfection, heating, blanching, pre-cooking, preparation, boiling, cooking and concentration.
At the same time, the jacketed pot is also suitable for large hotels, restaurants, hotels, guest houses, restaurants, industrial and mining enterprises, government agencies, and college canteens, as porridge, soup, dumplings, cooking and stewing.
At the same time, the jacketed pot is also suitable for large hotels, restaurants, hotels, guest houses, restaurants, industrial and mining enterprises, government agencies, and college canteens, as porridge, soup, dumplings, cooking and stewing.
introduce
The electric heating jacketed pot is heated by 380V electricity as the heat source. It has two structures: vertical and tiltable. The jacketed pot with stirring or without stirring can be selected according to the actual situation. The pot body of Runlu jacketed pot is composed of inner and outer spherical. The pot body is composed of a double-layer structure, and all materials are produced and manufactured with food-grade 304 high-quality stainless steel according to national health standards.
The electric heating jacketed pot is not only beautiful in appearance, but also easy to operate, safe and convenient, with a large heating area and uniform and controllable temperature. Pharmaceutical and daily chemical industries are good equipment for food processing to improve quality, shorten time and improve working conditions.
The electric heating jacketed pot is not only beautiful in appearance, but also easy to operate, safe and convenient, with a large heating area and uniform and controllable temperature. Pharmaceutical and daily chemical industries are good equipment for food processing to improve quality, shorten time and improve working conditions.
Why must choose us
Details
Our factory
Henan ZGCM Machinery Co.,Ltd. has a plant area of more than 10,000 square meters, which produces vertical packaging machines, automatic material sorting lines, pillow packaging machines, filling machines, etc. Among them, granule packaging machine, powder packaging machine, liquid packaging machine, sauce packaging machine, food packaging machine, multi-head weighing machine, hardware packaging machine, counting packaging machine, medical supplies packaging machine, fresh fruit and vegetable packaging machine, filling machine, Capping series, unscramble bottle washing series, filling production line, etc. are the company's main products, which are exported to hundreds of countries and regions in Southeast Asia, Europe, America, Africa, the Middle East, etc., and are well received by users from all over the world! The company always adheres to the development strategy of "customer first, worry-free after-sales", pays attention to the reserve and training of talents, and has long-term exchanges of talents and technology with famous enterprises at home and abroad. The factory currently has more than 180 employees, including 35 in the R&D department, who are responsible for the R&D and design of non-standard equipment and advanced technology in the industry. The after-sales department has 30 masters with more than 20 years of after-sales experience, who are responsible for the installation of equipment sold at home and abroad. Commissioning, operation training and technical maintenance. We aim to realize enterprise packaging intelligence, liberate people from heavy packaging production, let machines replace manual work, reduce production costs, and improve production efficiency
Company history
Cooperation Case
Our client
transport
Frequently Asked Questions and Answers
1. Q: Do you have a finished machine to see?
Yes, we have standard machine inventory.
2. Q: Will you check before leaving the factory?
Yes it is. Every step of production and completion will be checked by QC department before shipment.
3. Q: Can overseas services be provided?
Yes, engineers can go abroad to train workers, install and debug machines for free
4. Q: How long is the warranty period?
One year machine warranty.
5. Q: What is the delivery time?
15-25 days after receiving the deposit.
Yes, we have standard machine inventory.
2. Q: Will you check before leaving the factory?
Yes it is. Every step of production and completion will be checked by QC department before shipment.
3. Q: Can overseas services be provided?
Yes, engineers can go abroad to train workers, install and debug machines for free
4. Q: How long is the warranty period?
One year machine warranty.
5. Q: What is the delivery time?
15-25 days after receiving the deposit.
