BOYA BY XM6 S1 S2 K1 K2 Wireless Lavalier Mic Microphone System for Smartphone Laptop DSLR Tablet Camcorder Recorder 100M
- Category: >>>
- Supplier: Shenzhen Jiayz Photo Industrial Co. Ltd.
Share on (1600527155711):
Product Overview
Description
Products Description
Receiver | ||
Transmission Type | 2.4GHz Digital Frequency | |
Modulation | GFSK | |
Operating Range (without obstacle) | Up to 328ft (100m) | |
Audio Output Connector | 3.5mm Headphone Jack | |
3.5mm TRS Output Jack | ||
Audio Output Level | –60 dBV to -20dBV | |
Power Requirements | Built-in Li-ion Battery USB-C DC 5V Charging Contact | |
Built-in Battery Life | Approx. 6.5 hours | |
Antenna | PIFA Antenna | |
Weight | Approx. 32g(1.13oz) | |
Dimensions | 62.1×31.6×16.5mm | |
Operating Temperature | –10°C to 50°C | |
Storage Temperature | –20°C to +55°C | |
Transmitter | ||
Transmission Type | 2.4GHz Digital Frequency | |
Modulation | GFSK | |
Operating Range (without obstacle) | Up to 328ft (100m) | |
RF Output Power | ＜10mW | |
Polar Pattern | Omnidirectional | |
Frequency Response | 50Hz-18KHz | |
Maximum SPL | Built-in Microphone: 120dB SPL | |
Lavalier Microphone: 110dB SPL | ||
Sensitivity | Built-in Microphone: -39dB | |
Lavalier Microphone: -39dB | ||
SNR | > 84dB | |
Power Requirements | Built-in Li-ion Battery or USB-C DC 5V or Charging Contact | |
Built-in Battery Life | Approx. 7 hours | |
Antenna | PIFA Antenna | |
Audio Inputs | 3.5mm TRS MIC/LINE IN Jack or Built-in Microphone | |
Weight | Approx. 32g(1.13oz) | |
Dimensions | 62.1×31.6×16.5mm | |
Operating Temperature | –10°C to 50°C | |
Storage Temperature | –20°C to +55°C | |
The BOYA BY-XM6-S1, a 2.4GHz adaptive frequency hopping wireless microphone system, consists of one transmitter and one receiver.It’s a perfect sound capturing and delivering solution for one-person vlog, YouTube video, live streaming, interview,recording,etc.
Advanced Technology for Stable Signal Transmission
The BY-XM6-S1 adopts advanced Adaptive Frequency Hopping (AFH) wireless signal transmission technology, which can make the BY-XM6-S1 avoid the disturbed hop frequency parts automatically to realize stable signal transmission in the range of up to 100m (328ft),without obstacle.
Professional Audio Capturing & Delivering
Featuring a high-quality capsule and signal processing circuit with a signal-to-noise over 84dB and a distortion rate less than 0.1%, the BY-XM6 S1 captures and delivers high-quality , clear and low-noise audio.
Ultra-versatile & Ease-to-use Wireless Microphone Kit
With vivid and easy-to-read OLED display on transmitter and receiver,users can adjust the signal transmission precisely. And the transmitter is also designed with a built-in omnidirectional microphone, so users can clip the transmitter on the collar to pick up sounds, while they can also plug a lavalier microphone into transmitter’s MIC IN jack for sound capturing.
This microphone kit is equipped with both 3.5mm TRS
TRS audio cable and 3.5mm TRS-TRRS audio cable. So it can work well with your DSLR or mirrorless camera, smartphone and computer.With headphone output jack on receiver for real-time monitoring. Stereo and mono outputs are available and switchable on receiver. Built-in Li-ion batteries for 7h use on transmitter and 6.5h use on receiver.
Perfect Audio Solution
The BOYA BY-XM6 is a 2.4GHz adaptive frequency hopping wireless lavalier microphone system, consists of one transmitter and one receiver. It’s a perfect sound capturing and delivering solution for one-person vlog, YouTube video,
live streaming, interview, recording, etc.
live streaming, interview, recording, etc.
Long Operation Distance
BOYA wireless lavalier microphone BY-XM6 uses the 2.4Ghz transmission frequency band and can support up to 328ft of barrier-free transmission distance, and no longer suffers from the trouble of being bound by wires.
Long Battery Life
Professional Audio Capturing & Delivering--Featuring a high-quality capsule and signal processing circuit. Built-in rechargeable lithium battery, can work continuously for 7 hours. Type-C interface, support on-the-go charging, no stress during the whole day of shooting.
OLED Display
BY-XM6 is an easy-to-use Cordless Wireless Microphone Kit-- With vivid and easy-to-read OLED display on transmitter and receiver, users can adjust the signal transmission precisely.
Built-in Mic & External Lapel Mic
Each transmitter is with a lav mic and also designed with a built-in omni-directional microphone, so users can clip the transmitter on the collar to pick up sounds, while they can also plug a lavalier microphone into transmitter’s MIC IN jack for sound capturing. And External Lapel Mic is also included.
MUTE
Short press the mute button to mute on or mute off , long press the mute button to power on or power off. When mute is on, the recorder logo on the screen will have a cross.
