Pure PTFE suspension powder 16 used for Insulating film

Product Overview

Description

Pure PTFE suspension powder 16 for insulating film for electric



Technical Index



Item	Unit	16A
Appearance	——	white powder, no impurities
Tensile Strength	Mpa≥	30
Elongation at Break	%≥	300
Bulk density	g/L	300-450
Water content	%≤	0.04
Particle size	um	20-25
Melting peak temperature	℃	327±5
Standard specific gravity	——	2.140-2.170
Thermal instability index	——≤	20
Electric strength	MV/m≥	80



Processing method   Molding



Main Application

The resin are mainly used as insulating film for electric, the products of thin wall, seal, gasket, club, panel, tube, axletree, seal ring, and loop etc

Package, transportation and storage

1). PTFE is packed in double layer PVC bags inside and in hard circular barrels outside.20kg/barrel. On the barrel, there should be attached label and quality certificate.

2). PTFE should be stored in clean dry warehouse to prevent from dust, moisture, etc, foreign maters.

3). The product are transported according to non-dangerousproducts.

Heat, moisture, freezing and strong shock should be avoided during transportation. Over-bumpiness and compression is adapt to make the resin bind together.
