Product Overview
Description
Product Description
High Performance
*Support 3G/4G and wired WAN dual link backup（Optional）.
*Multiple WAN connection methods, include Static IP/DHCP/PPPOE/DHCP-4G
*Support Load Balancer and Load Shunt (Only for dual sim dual module version)
*Support APN/VPDN
*Support NTP, RTC embedded.
*Support multiple DDNS provider service
*Support multiple online trigger ways,including SMS, ring and data. Support link disconnection when timeout
*Support remote management, SYSLOG, SNMP, TELNET, SSHD, HTTPS, etc.
*Support upgrade software from the local and remote maintenance.
*Support SPI firewall, access control, URL filtering, etc.
*WIFI 802.11b/g/n/ac. Support AP/AP Client/Bridge mode (Optional).
*VPN Tunnel: PPTP/L2TP/OPENVPN/IPSEC/GRE
*Support TCP/IP, UDP, FTP (Optional), HTTP and other network protocols
*Support DHCP server and DHCP client, NAT, DMZ, QOS.
*Schedule Reboot, Schedule Online and Offline, etc.
*Support GPS function (Optional)
*Multiple WAN connection methods, include Static IP/DHCP/PPPOE/DHCP-4G
*Support Load Balancer and Load Shunt (Only for dual sim dual module version)
*Support APN/VPDN
*Support NTP, RTC embedded.
*Support multiple DDNS provider service
*Support multiple online trigger ways,including SMS, ring and data. Support link disconnection when timeout
*Support remote management, SYSLOG, SNMP, TELNET, SSHD, HTTPS, etc.
*Support upgrade software from the local and remote maintenance.
*Support SPI firewall, access control, URL filtering, etc.
*WIFI 802.11b/g/n/ac. Support AP/AP Client/Bridge mode (Optional).
*VPN Tunnel: PPTP/L2TP/OPENVPN/IPSEC/GRE
*Support TCP/IP, UDP, FTP (Optional), HTTP and other network protocols
*Support DHCP server and DHCP client, NAT, DMZ, QOS.
*Schedule Reboot, Schedule Online and Offline, etc.
*Support GPS function (Optional)
Specification
Cellular Specification | ||||||||
Standard and Band | LTE FDD: B1/B3/B5/B7/B8/B20/B28 B1/B2/B3/B4/B5/B7/B8/B28 (Optional), B2/B4/B5/B12/B13/B17/B66/B71 (Optional) LTE TDD:B38/B39/B40/B41 HSPA+/HSUPA/HSDPA/WCDMA/UMTS 2100/1900/900/850MHz EV-DO: BC0 CDMA 1x: BC0 EDGE/GPRS/GSM 850/900/1800/1900MHz | |||||||
Bandwidth | LTE CAT4: 150Mbps(DL), 50Mbps (UL) LTE CAT6: 300Mbps(DL), 50Mbps (UL) LTE CAT12: 600Mbps(DL), 150Mbps (UL) DC-HSPA+: 42Mbps(DL), 5.76 Mbps(UL) HSPA+：21 Mbps(DL), 5.76 Mbps(UL) HSDPA：7.2 Mbps(DL), HSUPA：5.76 Mbps(UL) UMTS：384Kbps | |||||||
Transmit Power | < 23dBm | |||||||
Sensitivity | < -97dBm | |||||||
WIFI Specification | ||||||||
Standard and Band | Support IEEE802.11b/g/n, 2.4G, Support IEEE802.11ac, 5.8G | |||||||
Bandwidth | IEEE802.11b/g：Maximum speed rate up to 54 Mbps (108Mbps optional) IEEE802.11n：Maximum speed rate up to 150 Mbps (300Mbps optional) IEEE802.11ac：Maximum speed rate up to 390 Mbps (780Mbps optional) | |||||||
Security | Support WEP, WPA, WPA2 encrypt methods, optional WPS function | |||||||
Transmit Power | 26dBm (11b), 21.5dBm (11g), 20dBm (11n), 16dBm (11ac) | |||||||
Sensitivity | < -72dBm @ 54Mbps | |||||||
Interfaces | ||||||||
WAN Interface | 1 x Gigabit RJ45 ethernet port, adaptive MDI/MDIX, built-in 15KV ESD | |||||||
LAN Interface | 4 x Gigabit RJ45 ethernet port, adaptive MDI/MDIX, built-in 15KV ESD | |||||||
Serial | 1 x RS232/RS485 serial interface with built-in 15KV ESD Data bits:5, 6, 7, 8 bits Stop bits:1, 1.5 (optional), 2 bits Error detection: none, even parity, odd parity, SPACE (optional) and MARK (optional) Serial Port Rate: 2400~115200bits/s | |||||||
LED Indicators | "PWR", "SYS", "WIFI", "SIM", "Online", "Signal Strength" | |||||||
I/O Ports | 6-pin 3.5mm wiring terminal, 2 inputs, 1 output, 1 relay; Controlled by Modbus protocol Input high level: 5 to 30 VDC Input low level: 0 to 3 VDC Load current: 50mA @ 30VDC Relay load 1A 250V AC/ 30V DC | |||||||
Antenna Interface | Cellular: 2 * Standard SMA female antenna interface, characteristic impedance: 50 Ω WIFI: Standard SMA male antenna interface, characteristic impedance: 50 Ω | |||||||
SIM/UIM Slot | Standard drawer type user card interface, support 1.8V/3V SIM/UIM card, built-in 15KV ESD, support dual-SIM card (optional) | |||||||
Power Interface | Terminal power socket | |||||||
Reset Button | Can reset router’s configuration to default factory setting by this button | |||||||
