Professional Audio DJ Controller 32 Channels MIC input Digital Console With Touch Screen Support IOS Android Windows System
- Category: >>>
- Supplier: Guangzhou Marco Electronics & Technology Co. Limited
Share on (1600530520188):
Product Overview
Description
Specification
T32:32 CHANNELS DIGITAL MIXER
Product parameters
1. 32 MIC inputs 1 stereo input
2. Digital Input: Optical/Sound Card, MP3
3. Input channel pan adjustment
4. MIC input gain adjustment (digital gain)
5. +48V phantom power (MIC channels can be turned on and off independently)
6. Built-in compressor, high and low pass, 5-band parametric equalization, delay, audio image balance adjustment of input channels
7. Channel parameter quick copy function
8. I/O EQ ON/OFF
9. Multifunction Knob
10. Multi-function menu for each channel, mute and monitor
11. All channels are equipped with travel 100MM electric faders, signal and peak lights (33 ALPS electric faders)
12. 12-channel signal output (main output L, R, 6-channel AUX output, 4-channel group output)
13. AUX output (pre/post fader)
14. Output processing: high and low pass filtering, 15-band parametric EQ, compressor, delay, phase
15. Digital recording function
16. Double row 3-color 12-segment level indicator
17. Built-in sound card (MP3, PC direct music playback)
18. 4 quick scene recall modes, 20 scene storage
19. Storage and recall of user parameters (can be managed on PC)
20. Built-in four-way dual DSP effects
21. FX Foot Switch Connector
22. Optical input/output
23. Multi-operating system control software (IOS system, Android
24. system, WINDOWS system)
25. Support wired network port adjustment (or wireless adjustment with external router)
26. 7 inch 800*480 capacitive touch screen
27. User-definable layer, output blending editing function
1. 32 MIC inputs 1 stereo input
2. Digital Input: Optical/Sound Card, MP3
3. Input channel pan adjustment
4. MIC input gain adjustment (digital gain)
5. +48V phantom power (MIC channels can be turned on and off independently)
6. Built-in compressor, high and low pass, 5-band parametric equalization, delay, audio image balance adjustment of input channels
7. Channel parameter quick copy function
8. I/O EQ ON/OFF
9. Multifunction Knob
10. Multi-function menu for each channel, mute and monitor
11. All channels are equipped with travel 100MM electric faders, signal and peak lights (33 ALPS electric faders)
12. 12-channel signal output (main output L, R, 6-channel AUX output, 4-channel group output)
13. AUX output (pre/post fader)
14. Output processing: high and low pass filtering, 15-band parametric EQ, compressor, delay, phase
15. Digital recording function
16. Double row 3-color 12-segment level indicator
17. Built-in sound card (MP3, PC direct music playback)
18. 4 quick scene recall modes, 20 scene storage
19. Storage and recall of user parameters (can be managed on PC)
20. Built-in four-way dual DSP effects
21. FX Foot Switch Connector
22. Optical input/output
23. Multi-operating system control software (IOS system, Android
24. system, WINDOWS system)
25. Support wired network port adjustment (or wireless adjustment with external router)
26. 7 inch 800*480 capacitive touch screen
27. User-definable layer, output blending editing function
technical parameter | ||||||||||
Input | Mic/Line input：1-32 | balance，XLP and 1/4 TRS jacks | control | fader | ALPS 100mm electric | |||||
Input sensitivity（XLR/TRS） | XTR1.5mv,TRS changed to 7mv | touch screen | 7”TFT，800×480 Resolution | |||||||
Input analog gain | -32db to 10db , 0.6~0.7步进 | output group | YES | |||||||
maximum input level（XLR/TRS） | +19dBu/+29dBu | mute group | No | |||||||
input impedance（XLR/TRS） | MIC＞5K ，LINE＞10K | Network | TCP/IP Ethernet for PC and iPad applications | |||||||
Mic input stereo link | YES | system upgrade | U disk upgrade | |||||||
parameter link | Equalization, Dynamics, Delay, Distribution, Send | wired connection | Windows PC software connection | |||||||
polarity | normal/flip | Wireless connections | Windows PC/iPad/android | |||||||
Stereo line input | input processing | input source | Local CH1-CH32, ST1 local ST2 digital | |||||||
ST1 | balance，1/4 TRS jack | Equalizer | 5 segment parametersEQ, (20HZ--20KHZ)±12dB,Q0.3~15可调 | |||||||
ST2 port (digital) | USB audio streaming, U disk, S/PDIF | High and low pass | 12db/24db,(BT/BS/LRK),20-20K | |||||||
Input sensitivity | Nominal 4dB | noise gate | Self-chain sidechain | |||||||
Input analog gain | -32db to 10db , 0.6~0.7步进 | gate threshold | -135db to -40db | |||||||
maximum input level | +29dB | shock/release | 50us-300ms/10ms-5s | |||||||
input impedance | >7KΩ | compressor | Self-chain sidechain | |||||||
Stereo link | YES | Threshold ratio | -40db-+6db/1:1 to infinity | |||||||
parameter link | Equalization, Dynamics, Delay, Distribution, Send | delay | 20ms max | |||||||
polarity | normal/flip | |||||||||
Output | Mix 1-10 with left and right outputs | balance，XLR，L/R,4SUB,6AUX | output processing | output channel | L/R,4SUB,6AUX | |||||
output impedance | <75Ω | Equalizer | 15 segment parametersEQ, (20HZ--20KHZ)±12dB,Q0.3~15可调 | |||||||
Nominal output | +4dbu=0db level meter reading | High and low pass | 12db/24db,(BT/BS/LRK),20-20KHZ | |||||||
residual output noise | =-91dbu | compressor | Self-chain sidechain | |||||||
mix insert | Assign FX to mix channel | Threshold ratio | -40db-+6db/1:1 to infinity | |||||||
Dynamic Range | 112dB | delay | 30ms max | |||||||
SNR | XLR≥ 92db,TRS≥82db | USB | driver | CH340(USB A) | ||||||
Maximum output voltage | 4VAC MAX | equipment | Use a USB hard disk (U disk) | |||||||
Distortion | ＜0.0003%（1KhzFull Power） | Stereo recording | 2 channels(wav/mp3)48KHz 24 | |||||||
Frequency response | 20HZ-20KHZ+/-0.5db | Stereo playback | 2 channels(WAV/MP3)32-96KHz, 16-24位 | |||||||
Sampling Rate | 48KHz ±100PPM | USB audio | sound card | USB B | ||||||
ADC/DCA | 24位Delta-sigma | send upstream | 2 channel full format， 32KHz-96KHz 24位 | |||||||
FX | Internal FX | 4xFX Engine, Send > Return or Insert | send downstream | 2 channels，MP3,48KHz,24位 | ||||||
Types | Reverb, Delay, Chorus, Flanger, Symphonic Chorus, etc. | |||||||||
4 dedicated stereo FX returns | Fader, Pan, Mute, Send to Mix/LR, 5-band EQ | |||||||||
system | Linux system | Chinese and English language switching | power supply | 100-240VAC,50-60H,150W | ||||||
size/weight | ||||||||||
dimension：791*515*215MM（length includes 6.35 Input socket, width includes side plate, height includes feet; does not include knob） | ||||||||||
Netweight：15.28KG Gross weight：18.2KG | ||||||||||
Packing size：920*620*310MM | ||||||||||
Applications: conference rooms, multi-function halls, small performances, small bands, government, schools, bars, wedding companies, leasing companies, banquet halls, military, cultural halls, cultural centers, exhibitions, etc. | ||||||||||
Product packaging
Our Advantages
FAQ
1. How about your quality?
Boutum is an old manufactuer, quality was proved, our biggest feature is DURABLE and STABLE! Our speakers able to be used about 10
years by some of our clients.
2. Can I have a sample order?
Yes, sample order is acceptable to check quality and design.
3. Do you offer OEM or ODM service?
Yes, we have our own R&D, production, marketing, after-sales department, OEM & ODM service is available.
4. What is your guarantee period?
3 years warranty, life time maintenance
5. What is your delivery time?
We have stock ensure samples quick sending. For bulk, 7-20 days after receiving the deposit.
6. Are you a manufacturer?
Yes. Boutum Audio is a professional speakers and amplifiers manufacturer with 24 years since 1992. With a rich experience in R&D,
manufacturing, exporting and sound project. At the same time, is agent of Pioneer DJ Equipment OVER 15 years.
Boutum is an old manufactuer, quality was proved, our biggest feature is DURABLE and STABLE! Our speakers able to be used about 10
years by some of our clients.
2. Can I have a sample order?
Yes, sample order is acceptable to check quality and design.
3. Do you offer OEM or ODM service?
Yes, we have our own R&D, production, marketing, after-sales department, OEM & ODM service is available.
4. What is your guarantee period?
3 years warranty, life time maintenance
5. What is your delivery time?
We have stock ensure samples quick sending. For bulk, 7-20 days after receiving the deposit.
6. Are you a manufacturer?
Yes. Boutum Audio is a professional speakers and amplifiers manufacturer with 24 years since 1992. With a rich experience in R&D,
manufacturing, exporting and sound project. At the same time, is agent of Pioneer DJ Equipment OVER 15 years.
