4g module ec20 series New EC20CE LTE Cat 4 wireless module EC20CEFHLG 128 SNNS with GPS wifi Multiple BandInfo
- Category: >>>
- Supplier: Shenzhen Wuji Electronics Co. Ltd.
Share on (1600530661469):
Product Overview
Description
4g module ec20 series Quectel EC20-CE LTE Cat 4 wireless communication module EC20CEFHLG-128-SNNS with GPS wifi interface
Products Description
Key Features
LTE Cat 4 wireless module designed for M2M and IoT applications
Comprehensive coverage of various network standards
Integrated multi-constellation GNSS receiver to meet the needs of fast and accurate positioning in different environments
Supports DFOTA and DTMF functions
MIMO technology meets the data rate and connection reliability requirements of wireless communication systems
Overview
EC20 R2.1 is an LTE Cat 4 wireless communication module recently launched by Quectel. It adopts LTE 3GPP Release 11 technology and supports a maximum downlink rate of 150 Mbps and a maximum uplink rate of 50 Mbps; at the same time, the package is compatible with Quectel's multi-network standard LTE. EC21 series, EC25 series and EG25-G modules realize seamless switching between 3G network and 4G network.
EC20 R2.1 adopts the laser engraving process, which has the advantages of more beautiful appearance, strong metal texture, better heat dissipation, information is not easy to be erased, and more suitable for automation needs.
EC20 R2.1 has built-in multi-constellation high-precision positioning GNSS (GPS/GLONASS/BeiDou/Galileo/QZSS) receiver; while simplifying product design, it also greatly improves positioning speed and accuracy.
EC20 R2.1 has built-in rich network protocols, integrates multiple industry standard interfaces, and supports multiple drivers and software functions (applicable to USB drivers under Windows 7/8/8.1/10, Linux, Android and other operating systems, etc.), It greatly expands the application scope of EC20 R2.1 in the field of M2M, such as CPE, router, data card, tablet computer, vehicle, security and industrial PDA, etc.
Product Paramenters
Product Name（Module） | EC20CEFHLG-128-SNNS |
Module Type | LTE Cat 4 module |
Other OC | EC20CEFAG-512-SGNS EC20CEFAG-512-SGNSX EC20CEFAG-512-SGNSQ EC20CEFASG-256-SGNS EC20CEHCLG-128-SNNS EC20CEHCLG-128-AUD EC20CEFHLG-128-SNNS EC20CEFILG-128-SGNS EC20CEFALG-128-SGNS EC20CEHDLG-128-SNNS EC20CEFRG-512-SGNS EC20CEFRG-512-SGNSQ EC20CEFRSG-256-SGNS |
BandInfo | FDD:B1/B3/B5/B8 TDD:B34/B38/B39/B40/B41 WCDMA:B1/B8 TD-SCDMA:B34/B39 EVDO/CDMA: BC0 GSM:B3/B8 |
Form Factor | LCC |
Details Images
The above parameters are for reference only, and the actual situation shall prevail.
We have a strong technical team that can provide all product specifications, hardware, software, development boards and other documentation and technical guidance.
If you need these materials and technical guidance, please contact us! (click here)
