one way sprag clutch bearing dc222G n dc2776 n dc3034 n dc3809A n dc4127(3c) n dc4445a n
- Category: >>>
- Supplier: Cixi Jiaxing Bearing Co. Ltd.
Share on (1600531194627):
Product Overview
Description
Dear, the product price is a virtual price, please contact us first ！！
We produce a full range of bearing types, provide one-stop procurement service, if you are interested in other products, please contact us, you can enjoy free sample service.
email: fofbearing@163.com
WeChat：xx18102660984 or
Product Configuration
The DC model is a wedge retainer one-way clutch but does not include an inner ring and an outer ring. This model must match the inner ring and outer ring designed by the customer. The bearing supports axial and radial loads as well as lubricating grease and oil seals. The wedge fast contact surface and the space tolerance must be within the range.
The width of the contact surface between the outer ring and the inner ring must not be less than the dimension "e", and the contact surface must not have any grooves to ensure normal function. Our factory can provide standard inner ring and outer ring. If you manufacture the hardened steel shaft and the workpiece directly into the machine wall, please participate in the following surface hardness specifications. The hardness of the contact surface processed by grinding is HRC60~62 and the hardening depth must be greater than 0.6mm. The internal hardness of the contact surface is HRC35~45, the surface smoothness of the contact surface must be greater than 22CLA, and the maximum acceptable skewness of the contact surface is 25mm and 0.007mm in width.
The width of the contact surface between the outer ring and the inner ring must not be less than the dimension "e", and the contact surface must not have any grooves to ensure normal function. Our factory can provide standard inner ring and outer ring. If you manufacture the hardened steel shaft and the workpiece directly into the machine wall, please participate in the following surface hardness specifications. The hardness of the contact surface processed by grinding is HRC60~62 and the hardening depth must be greater than 0.6mm. The internal hardness of the contact surface is HRC35~45, the surface smoothness of the contact surface must be greater than 22CLA, and the maximum acceptable skewness of the contact surface is 25mm and 0.007mm in width.
All of the above series models are available, please contact us first
Product Specifications
product name | needle bearing |
material | GGr15 |
feature | high precision, low noise, high speed, long life |
package | 1. Industrial packaging 2. Commercial packing 3. According to customer's requirements |
precision | P0 P6 P5 P4 |
noise | Z1 Z2 Z3 Z4 |
Delivery time | 1.For samples: 2-5days 2. For order: Generally 15-30 days |
Market | all over the world |
Payment terms | A：100%TT B:：30% T/T in advance. 70% before shipment or against copy of B/L C：Western union and PayPal |
Our Advantages
1."One-stop" work style
2.Warehouse sales and small volume orders
3.OEM service
4.Customize non-standard products and services according to customer drawings
5.dispatch goods on time
Application
Company Profile
Jiaxing Bearing Co., Ltd. is a supplier integrating production and trade of bearings, providing global customers with one-stop procurement services for bearings and power transmission products, with OEM and customized non-standard products and purchasing services according to customer drawings! Serving different customers with sincere and pragmatic spirit, we are willing to establish long-term and stable cooperative relations with friends all over the world. Work together to push the business to a higher level! Welcome friends from all over the world!
Production Process
Packaging Logistics
FAQ
Q1:Are you a trading company or a manufacturer?
Q2:Can you accept OEM and custom?
Q3:how long is your delivery time？
Q4:What is your payment terms?
Q5:What's your after-sales service?
A1:We are a factory and trade integrated supplier.
Q2:Can you accept OEM and custom?
A2:Yes, we can customize according to the samples and drawings you provided.
Q3:how long is your delivery time？
A3:If stock in 7days or base on your order quantity.
Q4:What is your payment terms?
A4: Western Union, TT, Paypal, Alibaba Trade Assurance.
Q5:What's your after-sales service?
A5:According to each contract between the two parties to assume the corresponding responsibilities.
