nickel ore mobile crushing plant price
- Category: >>>
- Supplier: Jiaozuo City Xinhai Mine Machinery Equipment Plant(General Partnership)
Share on (1600531410478):
Product Overview
Description
Product Description
Jaw Crusher is suitable for primary and secondary crusher for material with compression strength less than 320MPA. Jaw Crusher is widely used in mining, metallurgy, construction, highway, railroad, and water conservancy, etc.
Jaw Crusher Features
1,Discharge opening of the jaw crusher is adjustable reliably within a wide range through the stuffing of shim, thus it is capable to meet various requirements of customers.
2,Lubrication system of it is safe and reliable, which boasts an easy and convenient maintenance.
3,Simple structure, reliable performance, low maintenance cost
4,Little dust and low noise
Jaw Crusher Working Principle![]()
The electrical motor transmits power to the eccentric shaft through v-belt and belt pulley. Then the exciting force generated by the eccentric shaft will make the movable jaw move upwards and downwards. This movement would trigger the toggle plate to push the movable jaw forwards and backwards.
When the movable jaw moves forth towards the fixed jaw, materials in the crushing cavity will be squashed or chopped. And then the movable jaw travels back, the chopped or squashed materials which meet the requirement will be discharged from the outlet. Since the motor keeps working. The crusher will crush and discharge periodically to achieve mass production.
Jaw Crusher Specification![]()
| Model | Feeding size(mm) | Max feeding size(mm) | Discharging Range size(mm) | Capacity (t/h) | Motor power(kw) | Weight (t) | Overall dimension(LxWxH)(mm) |
| PE-250*400 | 250*400 | 210 | 20-60 | 5-20 | 15 | 2.8 | 1180×1087×1245 |
| PE-400*600 | 400*600 | 340 | 40-100 | 16-60 | 30 | 6.65 | 1797×1716×1581 |
| PE-500*750 | 500*750 | 425 | 50-100 | 40-110 | 55 | 11.73 | 2119×1918×2046 |
| PE-600*900 | 600*900 | 500 | 65-180 | 80-180 | 55-75 | 16.13 | 2309×2028×2368 |
| PE-750*1060 | 750*1060 | 630 | 80-180 | 110-320 | 90-110 | 30 | 2730×2472×2840 |
| PE-870*1060 | 870*1060 | 750 | 170-270 | 180-360 | 90-110 | 31.22 | 2990×2416×2893 |
| PE-900*1200 | 900*1200 | 780 | 95-225 | 220-450 | 110-132 | 49 | 3362×2750×3260 |
| PE-1000*1200 | 1000*1200 | 850 | 195-280 | 280-550 | 110-132 | 51 | 3435x3182x3025 |
| PE-1200*1500 | 1200*1500 | 1020 | 150-300 | 400-800 | 160-220 | 100.9 | 4930×3334×4057 |
| PEX-150*750 | 150*750 | 120 | 18-48 | 8-25 | 15 | 3.5 | 1252×1593×1025 |
| PEX-250*750 | 250*750 | 210 | 20-50 | 13-35 | 30 | 4.96 | 1435×1832×1715 |
| PEX-250*1000 | 250*1000 | 210 | 25-60 | 16-52 | 30-37 | 6.5 | 1706×1964×1380 |
| PEX-250*1200 | 250*1200 | 210 | 25-60 | 20-61 | 37-45 | 8.8 | 1700×2132×1450 |
| PEX-300*1300 | 300*1300 | 250 | 20-90 | 25-95 | 55-75 | 12.6 | 2026×2320×1723 |
Global cooperation
Packaging Details:
We will load different sizes of packing according to different machine sizes, and the normal packing is in wooden cases. If exported to European countries, wood frame will be fumigation. If the container is too tight, we will use the PE film according to the customer's special requirements.
Delivery time
We are based on the actual needs of customers, to carry out tailor-made sales. By senior engineer to design scheme, after receipt of customer deposits began production, regardless of the size of the equipment we can deliver the goods in two weeks, delivered the balance after delivery.
Certifications
Twenty years of manufacturing expencice enable our products already have been exrensivly used in metallurgy,beneficiation,city constrction,road constrction,also refractory materral industry.Besides expansion on domestic market,our products have also been exported to Canda,Russia,India,Mongolia,South Afica,Central Asia,Weaten Asia and other cnuntries and regions.
Our Service
Pre-Sale Service
1) Inquiry and consulting support.
2) Pre-sale service: Freely provide project designing, process designing, choosing suitable equipment for you.
3) View our Factory. Field trips to sell products.
2) Pre-sale service: Freely provide project designing, process designing, choosing suitable equipment for you.
3) View our Factory. Field trips to sell products.
After -Sale Service
1) After acceptance of the equipment, we will draft the construction program and detailed process, and complete the export process.
2) After-sales service: We sent engineer to the scene to guide installation, debugging and training operators.
2) After-sales service: We sent engineer to the scene to guide installation, debugging and training operators.
Company culture
Xinhai Heavy industry, a modern mining machinery manufacturer, is specialized in researching and developing, manufacturing and selling multi-cylinder hydraulic cone crusher. It is located in Boai Industrial District of Jiaozuo City in Henan Province, China, covering an area of more than 133,334 m2. One 20000m2 standard workshop has been built in the first phase with annual production capacity of 100 sets multi-cylinder hydraulic cone crusher and comprehensive annual output value of RMB 160,000,000.
Our Company
Jiaozuo Xinhai Mining Machinery is one high-tech enterprise, which involves R&D, production, sales and service as well. In the past 20 years, we devote to producing mining equipment, sand making machines and industrial grinding mills.Till now, our products are sold to 130 countries, being the popular equipment in global crushing and grinding industry.
After crushing effec
APPLICABLE MATERIALS:
Chemicals, Mine, Coal, Granite, Rock, Stone, Marble, Griotte, Calcium Carbonate, Domolite, Limestone, Limerock, Calcareous Stone, Conquina, Siliceous Limestone, Chromite Ore, Mineral, Cement, Concrete, Compound, Cobblestone, Iron Ore, Ironstone, Iron-mineral soils, Copper Ore, Azurite, Copper Sulphide Ore, Quartz Stone, Quartzite, Keli Stone, Silestone, Coal, Gold Ore, Basalt, Whinstone, Shaly, Shale, Mudstone, Nonferrous Metals Ore, etc.
RANGE OF APPLICATIONS:
Sand Making Plant, Construction Waste Recycling, Household Waste Processing, Labratory, Quarry, Road, Building, Cement Plant, Building, Highway, Chemical, Metallurge, Coal Mine, Gold Mine, Benification, Mineral Separation, Stone Production, Brick Making, Ore Dressing, etc.
If you need our machines ,please send us inquiry as soon as possilbe
Contact us
Your email address and telephone will not be shared or published!
Please fill in your need products and your message and do not forget mail and/or phone if you like to be contacted.
we are the professional machine manufacturer in China.
I need to ask you some details for sending you the more suitable quotation,
1.what is the raw material do you want to process?
2.what is the capacity per hour do you need?
3.what is the raw material input size?
4.what is the output size of your product?
Of course, free live-chat is available and you can get help immediately.Or you can send me email .
You can get the price list and a Xinhai representative will contact you within one business day.
I hope you can tell me these details,i will give you well quotation ASAP ,thanks. Your satisfaction is our great pursuit, we would like to sincerely for your service! We look forward to your inquiry!
