Factory Wholesale Tubing Peek Valve Plate Parts Oil Seal Gaskets Compressor Tube Ptfe

Product Overview

Description

Factory Wholesale Tubing Peek Valve Plate Parts Oil Seal Gaskets Compressor Tube Ptfe





Specification

Item	Diameter (mm)	Length (mm)
PTFE molded tube	φ<=200mm	100,120,150mm
PTFE molded tube	custom size	100,150mm



PTFE filled with other materials:

Filled materials	Common filled ratio ( Quantity %)	Main performances
Bronze	40, 60	Increases hardness and wear resistance;  Increases dimensional stability and compressive strength; Not suitable for corrosive or electrical applications
Graphite	5,  10,  15	Improves the deformation under load; Reduces initial wear;  Improves thermal and eletrical conductivity
Glass Fiber	10,  15,  25	Increases compressive strength, rigidity and wear.  Reduces creep and cold flow; Improve Dimensional Stability.
Carbon Fiber	10 ,  15,  25	Increases compressive strength, hardness, wear, and load properties.  Reduces creep and cold flow
POB  (polyphenyl ester)	5,  10,  15	Improve the lubrication performance; Enhance the mechanical strength; Increase using temperature
BaSO4	5,  10,  15	Increases compressive strength, hardness and wear resistance Reduces creep
SiO2	5,  10,  15	Increases hardness and wear resistance; Improve Dimensional Stability.
Glass beads	5,  10,  15	Reduces creep and cold flow; Lower density Increases hardness and wear resistance;
Others materials	PEEK(polyetheretherketone), PI(Polyimide), MoS2 etc



We also supply customized filled PTFE material sealing products .





PTFE material has excellent resistance for all chemical corrosion. Its friction coefficient is the lowest in plastics.Temperature changes do not affect its electrical insulation property. So PTFE often be called "plastic king". PTFE is suitable for making corrosion resistant parts, wear parts, seal, insulation parts and medical equipment parts.
