2022 High Quality Colorful Heat shrink Tube
- Category: >>>
- Supplier: Yueqing Yingfa Cable Accessories Co. Ltd.
Share on (1600533941585):
Product Overview
Description
2022 High Quality Colorful Heat shrink Tube
INFA heat shrinkable tubes are featured with halogen free, environmental protection, fire retardation, insulation, flexible, elasticity, low shrinkage temperature, rapid shrinkage, etc, are widely applied to wire connection, soldered joint protection, end treatment of wire, wire marking, rust prevention and corrosin protection of mental, insulation protection of resistor and capacitor, etc. The large tubes can be applied to copper-bar, aluminum-bar and other low-voltage tank brackets, shrindageratio is 2:1.
Color: black, red, green, yellow, blue, white, transparent, yellow/green(other colors can be customized)
| Specification mm | As Supplied | After Shrinkage | Cable Range | Packing (M/Roll) | |||
| mm 1.D | Thickness | mm 1.D | Thickness | ||||
| φ1.0/0.5 | 1.50±0.30 | 0.20±0.05 | 0.60 | 0.35±0.05 | 0.50-0.90 | 200 | |
| φ1.5/0.75 | 2.00±0.30 | 0.20±0.05 | 0.80 | 0.35±0.05 | 0.75-1.40 | 200 | |
| φ2.0/1.0 | 2.50±0.30 | 0.20±0.05 | 1.00 | 0.42±0.05 | 1.00-1.80 | 200 | |
| φ2.5/1.25 | 3.00±0.30 | 0.20±0.05 | 1.25 | 0.42±0.05 | 1.25-2.30 | 200 | |
| φ3/1.5 | 4.00±0.30 | 0.20±0.05 | 1.75 | 0.42±0.05 | 1.75-3.20 | 200 | |
| φ4.0/2.0 | 4.50±0.30 | 0.20±0.05 | 2.00 | 0.45±0.05 | 2.00-3.60 | 200 | |
| φ5.0/2.5 | 5.50±0.30 | 0.28±0.05 | 2.50 | 0.50±0.08 | 2.50-4.50 | 100 | |
| φ6.0/3.0 | 6.50±0.30 | 0.28±0.05 | 3.00 | 0.50±0.08 | 3.00-5.40 | 100 | |
| φ7.0/3.5 | 7.50±0.30 | 0.30±0.08 | 3.50 | 0.55±0.08 | 3.50-6.30 | 100 | |
| φ8.0/4.0 | 8.50±0.30 | 0.30±0.08 | 4.00 | 0.60±0.08 | 4.00-7.20 | 100 | |
| φ9.0/4.5 | 9.50±0.30 | 0.30±0.08 | 4.50 | 0.60±0.08 | 4.50-8.00 | 100 | |
| φ10.0/5.0 | 10.50±0.50 | 0.30±0.08 | 5.00 | 0.60±0.08 | 5.00-9.00 | 100 | |
| φ11.0/5.5 | 11.50±0.50 | 0.30±0.10 | 5.50 | 0.60±0.08 | 5.50-10.00 | 100 | |
| φ12.0/6.0 | 12.50±0.50 | 0.30±0.10 | 6.00 | 0.60±0.08 | 6.00-11.00 | 100 | |
| φ13.0/6.5 | 13.50±0.50 | 0.35±0.10 | 6.50 | 0.65±0.08 | 6.50-12.00 | 100 | |
| φ14.0/7.0 | 14.50±0.50 | 0.35±0.10 | 7.00 | 0.65±0.08 | 7.00-13.00 | 100 | |
| φ15.0/7.5 | 15.50±0.60 | 0.40±0.12 | 7.50 | 0.70±0.08 | 7.50-14.00 | 100 | |
| φ16.0/8.0 | 16.50±0.60 | 0.40±0.12 | 8.00 | 0.70±0.08 | 8.00-15.00 | 100 | |
| φ18.0/9.0 | 19.00±0.60 | 0.40±0.12 | 9.00 | 0.80±0.15 | 9.00-17.00 | 100 | |
| φ20.0/10.0 | 21.00±0.60 | 0.40±0.15 | 10.00 | 0.80±0.15 | 10.00-19.00 | 100 | |
| φ22.0/11.0 | 23.00±0.70 | 0.45±0.15 | 11.00 | 0.90±0.15 | 11.00-21.00 | 100 | |
| φ50.0/25.0 | 50.50±0.70 | 0.50±0.15 | 25.00 | 1.00±0.15 | 25.00-49.00 | 25 | |
| φ60.0/30.0 | 60.50±0.70 | 0.55±0.15 | 30.00 | 1.00±0.20 | 30.00-59.00 | 25 | |
| φ70.0/35.0 | 70.50±0.70 | 0.55±0.15 | 35.00 | 1.00±0.20 | 35.00-69.00 | 25 | |
new details
Excellent service and first-class after-sale service
•Provide professional sales person to communicate with you before the order.
•Provide optimum system solution based on each client's export.
•Provide strict check for each part and each process before export.
•Provide post-sale service, including installation, technical guide and training.
1.Are you factory or trading company?
Yes,we are manufacturing in Zhejiang ,China. We can give you the competitive price & after sale service.
2.Could I print my own logo on the bag?
Yes,your logo can be printed as your demand, we offer OEM service.
3.What terms of payment & price condition &do you accept & use?
Payment terms:T/T,LC,Paypal,Western union,etc.
Price conditions:FOB(Shanghai & Ningbo),EXW,C&F etc.
4.What money do you accept for wire transfer?
USD,CNY/RMB,EURO etc.
5. How many days will it take to delivery the goods?
It denpends on your order quantity,small quantity will delivery the goods in 1-7days,if your order is big enough ,it make take 10~15 days.
