BK7 optical right angle prism
- Category: >>>
- Supplier: Nantong Ruisen Optical Co. Ltd.
Share on (1600534951140):
Product Overview
Description
BK7 optical right angle prism
| right angle prism | |||||||
| material | BK7 or other optical glass | ||||||
| Dimension tolerance | +/-0.1mm | ||||||
| Angle Tolerance | ≤2″ ≤5″≤10″≤30″≤1′≤3′ | ||||||
| Flatness | 1λ@632.8nm---1/6λ@632.8nm | ||||||
| surface quality | 20/10,40/20,60/40 scatch and dig | ||||||
| Coating | Awalable upon request. | ||||||
Application:
right angle prism can be usd to deflect a beam by 90degree or 180degrdd wich depend on which face is entaance fance , please refer the image as below.
Note for Fused Silica Right Angle Prism:
(1). Besides Fused Silica, custom-made Right Angle Prisms, which are made of other optical materials,
such as N-BK7, N-SF11, Pyrex, etc. are available.
(2). Typical dimension is 5.0mm, 10.0mm, 12.7mm, 15.0mm, 20.0mm, 25.4mm, 30.0mm, dimension from
1.0x1.0x1.0 mm to 300.0x300.0x300.0 mm is available.
(3). Better precision such as 1 min., 30sec., 15sec., 10sec., and 5sec. is available.
(4). Typical bevel is 0.25mmx45o, other bevel from 0.1mmx45o to 0.5mmx45o is available upon request.
(5). Anti-Reflective(AR), High-Reflective(HR), Partial-Reflective(PR) coating prisms are available.
(1). Besides Fused Silica, custom-made Right Angle Prisms, which are made of other optical materials,
such as N-BK7, N-SF11, Pyrex, etc. are available.
(2). Typical dimension is 5.0mm, 10.0mm, 12.7mm, 15.0mm, 20.0mm, 25.4mm, 30.0mm, dimension from
1.0x1.0x1.0 mm to 300.0x300.0x300.0 mm is available.
(3). Better precision such as 1 min., 30sec., 15sec., 10sec., and 5sec. is available.
(4). Typical bevel is 0.25mmx45o, other bevel from 0.1mmx45o to 0.5mmx45o is available upon request.
(5). Anti-Reflective(AR), High-Reflective(HR), Partial-Reflective(PR) coating prisms are available.
Producing:
Packing:
Why chose us?
1 Service time: 24 hours waiting for you.
2.Fast Response: 2 hours within our worktime, 12 hours get off work.
3.Good Service: We can supply you from design,measure to coating one stop service.
