Automatic combination Cabinet door carved plate door cabinet wood disc brush polish sanding sander machine
Automatic combination Cabinet door carved plate door cabinet wood disc brush polish sanding sander machine
Automatic combination Cabinet door carved plate door cabinet wood disc brush polish sanding sander machine
Automatic combination Cabinet door carved plate door cabinet wood disc brush polish sanding sander machine
Automatic combination Cabinet door carved plate door cabinet wood disc brush polish sanding sander machine
Automatic combination Cabinet door carved plate door cabinet wood disc brush polish sanding sander machine
Automatic combination Cabinet door carved plate door cabinet wood disc brush polish sanding sander machine

Automatic combination Cabinet door carved plate door cabinet wood disc brush polish sanding sander machine

Share on (1600534975916):


Price:$5,500.00

Quantity:


Product Overview

Description



Product Details


Specifications for
630
1000
1300
The processing width mm
<630
<1000
<1300
Processing and the thickness of mm
2-110
2-110
2-110
Board processing mm length
>400
>400
>400
The disc motor KW power
1.5
1.5
1.5
The disc swing motor KW power
0.39
0.39
0.39
The vertical roller motor KW power
1.5
1.5
1.5
The vertical roller oscillating motor KW power
0.39
0.39
0.39
Long roll motor KW power
2.2
2.2
2.2
Lifting motor KW power
0.37
0.37
0.37
Work pressure Mpa
0.5
0.6
0.6
Conveyor speed m/s
5--25
5--25
5--25
The disc diameter in mm
180
180
180
Vertical roll long roll mm in diameter
300
300
300
Overall dimensions
Varies according to the order number of shaft
Body weight


Big mesh yarn of the long roll combination placed behind the process workpiece grinding more detailed
The number of long vertical mill roller and roller combination can according to the different for products to custom


The disc and the vertical roller equipped with swing motor to burnish becomes more detailed
Vertical roll individually adjust the height and speed, concave and convex workpiece streaking grinding effect is obvious


1, surface polishing machine is a new practical and efficient wood surface processing equipment. Machine equipment imported high-end top intelligence, thoroughly improve the accuracy of sheet for polishing, especially on the primer polishing accuracy, by domestic high-end customers consistent high praise .
2, this machine is dedicated to interior door, cabinet door, furniture and other shape curved surface polishing equipment. Is suitable for all kinds of solid wood, density board, stick the material such as pedal straight (such as door line, door frame, the line that play a base, frame, blinds, etc.), the wooden line L and class rules surface, surface, plane board, and special curved surface, primer of wooden door, cabinet door surface coarse fine sanding, grinding, polishing.
3, USES flexible, suitable for a variety of plate parts including plate, color plate surface treatment of the primer and primer grinding and polishing and substrate, white body grinding sanding..
4, machine running speed is adjustable, no noise. Disk combination of vertical roll long roll grinding, achieves the comprehensive no dead Angle.
