Wholesale Supply High Quality Chip Cool White Light Emitting Diode 0603 Smd Manufacturer Supplier Wholesale Odm Led Lamp Beads
- Category: >>>
- Supplier: Shenzhen Hongying Technology Co. Ltd.
Share on (1600535050840):
Product Overview
Description
Products Description
Applications
1, Indoor lighting applications
2, Flat backlight for LCD switch and symbol
3, Indicator and backlighting for all consumer electronics
4, Automotive electronics
Maximum Rating (Ta=25℃)
Parameter | Symbol | Typical | Unit | |||
DC forward current | IF | 30 | mA | |||
Pulse forward current | IPF*3 | 100 | mA | |||
Reverse voltage | VR | 5 | V | |||
Junction temperature | TJ | 125 | ℃ | |||
Operating temperature range | TOP | -40~105 | ℃ | |||
Storage temperature range | TSTG | -40~105 | ℃ | |||
Soldering temperature | TSD*2 | 260 | ℃ | |||
Thermal resistance junction/ solder point | RTHJ-S | 140 | ℃/W | |||
Thermal Resistance Junction/ Ambient Point | RTHJ-A | 280 | ℃/W | |||
Electrostatic Discharge (HBM) | ESD | 2000 | V | |||
Notes: 1, There is no maximum or typical voltage parameter. 2, For other ambient, limited setting of current will be depended on de-rating curves. 3, Duty 1/10, pulse width 0.1ms 4, The maximum of soldering time is 10 seconds in TSD | ||||||
Typical Product Characteristics (Ta=25℃)
Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Condition | ||||||
Forward Voltage | VF | 1.95 | - | 2.5 | V | IF= 20mA | ||||||
Luminous Intensity | Iv | 390 | 470 | - | mcd | IF= 20mA | ||||||
Dominant Wavelength | λd | 627 | - | 637 | nm | IF= 20mA | ||||||
Peak Wavelength | λp | - | 640 | - | nm | IF= 20mA | ||||||
Spectral Width 50% | ∆λ | - | 16 | - | nm | IF= 20mA | ||||||
Reverse Current | IR | - | - | 10 | uA | VR= 10V | ||||||
View Angle | 2θ1/2 | - | 120 | - | Deg | IF= 20mA | ||||||
Notes: 1, Measurement tolerance: Forward Voltage: ±0.1V, Luminous Intensity: ±10%Iv, Dominant Wavelength: ±1.0nm, Viewing Angle (2θ1/2): ±5%. 2, Electrical-optical characteristics (Ta= 25℃). | ||||||||||||
Dimensional Drawing
Notes:
1, All dimensions are in millimeters
2, Tolerance is ±0.1mm unless otherwise noted.
3, Specification are subject to change without notice.
