Cnc Lathe Ck6160*1000 Integral Bed Hard Rail Cnc Lathe Stepless Speed Change Numerical Control Machine
- Category: >>>
- Supplier: Tengzhou Datong Machine Tool Co. Ltd.
Share on (1600535211722):
Product Overview
Description
DTMC
Product Description
Main structural features of the machine tool:
1.This machine tool is a high-speed, advanced and highly reliable CNC machine tool. The bed base, bed body, head box and other main components are all casted with high-strength materials to ensure the long-term stability of the machine tool.
2.The machine tool has high position accuracy and smooth chip removal, suitable for high-speed and high-precision machining.
3.High-speed, high-precision and high-rigidity spindle, frequency conversion spindle motor, can reach higher spindle speed. The main shaft unit is assembled in the frequency conversion room. After assembly, it is operated at a constant temperature for 72 hours. After the machine is put on the machine, it is tested for 72 hours to ensure the reliability of high-speed and high-precision performance.
4. Optional electric tool post.
5. X, Z direction feed adopts precision ball screw, the servo motor is directly connected with the screw through the atmospheric pressure and low inertia imported elastic coupling, adopts advanced centralized automatic lubrication device, timing and quantitative automatic intermittent lubrication, stable work reliable.
6. The machine tool protection adopts a full protection design, with strong pleasantness, unique appearance, reliable waterproof and chip prevention, and convenient maintenance.
1.This machine tool is a high-speed, advanced and highly reliable CNC machine tool. The bed base, bed body, head box and other main components are all casted with high-strength materials to ensure the long-term stability of the machine tool.
2.The machine tool has high position accuracy and smooth chip removal, suitable for high-speed and high-precision machining.
3.High-speed, high-precision and high-rigidity spindle, frequency conversion spindle motor, can reach higher spindle speed. The main shaft unit is assembled in the frequency conversion room. After assembly, it is operated at a constant temperature for 72 hours. After the machine is put on the machine, it is tested for 72 hours to ensure the reliability of high-speed and high-precision performance.
4. Optional electric tool post.
5. X, Z direction feed adopts precision ball screw, the servo motor is directly connected with the screw through the atmospheric pressure and low inertia imported elastic coupling, adopts advanced centralized automatic lubrication device, timing and quantitative automatic intermittent lubrication, stable work reliable.
6. The machine tool protection adopts a full protection design, with strong pleasantness, unique appearance, reliable waterproof and chip prevention, and convenient maintenance.
Specification
Item | Model | Unit | Parameters |
Process capability | Maximum swivel diameter of bed | mm | Φ600 |
Maximum rotary diameter of trawl | mm | Ф350 | |
Maximum cutting diameter | mm | Φ600 | |
Maximum machining length | mm | 850 | |
Travel | X/Z axis maximum travel | mm | 300/1000 |
X/Z axis minimum displacement unit | mm | 0.001 | |
Spindle | Main shaft hole diameter | mm | Ф105 |
Spindle Series | Stepless | ||
Spindle Series | rpm | 20-1000 | |
Main motor power (frequency conversion) | kW | 11 | |
Frequency transformer | kW | 11 | |
X/Z axis | N.m | 5/7.5 | |
X/Z axis fast moving speed | m/min | 6/8 | |
Feed tool holder | Type of tool holder | 4-station electric tool holder | |
Tool Bar Size | mm | 25*25 | |
Repeated positioning accuracy of tool holder | mm | ≤0.004 | |
Tailstock sleeve diameter | mm | Φ75 | |
Tailstock sleeve travel | mm | 200 | |
Top cone of tail seat | MT 5# | ||
Net weight of machine | kg | 2800 | |
Machine tool size (length × width × height) | mm | 2940*1300*1680 | |
Other | Power requirements (power/current) | kW/A | 15kW/20A |
