No | Item | Data | ||||
1 | Wheel base(mm) | 2800; 3360; 3800; 4200; 4500; 4750; 5200'5600 | ||||
2 | Payload | 2T -- 10T | ||||
3 | Horse Power | 85hp; 95hp; 110hp; 116hp; 120hp;140hp; 160hp; | ||||
4 | Cabin | single cabin; king cabin; double cabin | ||||
5 | Cargo | cargo box; stake box; van box | ||||
6 | Drive | left hand drive; right hand drive | ||||
7 | Keywords | 4X2 Cargo Truck Van Truck Lorry Truck Light Truck | ||||

Cabin | Driving type 4x2 LHD single cabin two seats with A/C 70° | ||||||
Vehicle Main Dimensions | Overall dimensions for cargo truck | 6995*2330*2650 | |||||
Overall dimensions for van truck | 6995*2330*3300 | ||||||
Cargo Box size | 5150*2050*550 | ||||||
Van size | 5150*2050*2150 | ||||||
Wheel base (mm) | 3800 | ||||||
Wheel track (front/rear) (mm) | 1789/1764 | ||||||
Approach/Departure angle(°) | 27/22 | ||||||
Weight in KGS | Tare Weight for cargo truck | 4000 | |||||
Tare Weight for van truck | 4150 | ||||||
payload | 5000 | ||||||
Front axles loading capacity | 1x3000 | ||||||
Rear axles loading capacity | 1x6200 | ||||||
Max. driving speed(km/h) | 95 | ||||||
Engine | Brand | Yunnei | |||||
Type | 4 cylinder in line, water cooling Turbocharged and Intercooled | ||||||
Model | YN4102 | ||||||
Horse Power(HP) | 116 | ||||||
Emission standard | Euro Ⅱ | ||||||
Gearbox | WLY6T46 gearbox, 6-speed Forwards gear & 1 reverse gear | ||||||
Tire | 8.25R16 steel radial 7pcs including one spare tire | ||||||
