Adopt vertical blade and triangular double fulcrum design 12v 24v home on grid wind turbine
- Category: >>>
- Supplier: Guangzhou Funeng Electric Power Technology Co. ltd.
Share on (1600535778834):
Product Overview
Description
Guangzhou Funeng Electric Power Technology Co.,ltd.
Guangzhou Funeng is a processional, fast growing company. The company is well known as a world leading manufacturer of cost-effective, high efficiency and good quality photovoltaic panel, inverter, battery, controller and solar system,wind power system.
Features
*Security. Using the vertical blade and triangular double -fulcrum design, the main force points concentrated in the hub, so bla
*Rotation radius. Because of its design structure and special operating principle, it has a smaller radius of rotation than other types of wind turbines, it saves space, while improving efficiency.
*Power generation curve characteristics. Start wind speed is lower than other types of wind turbines, the power generation increasing rate is relatively gentle, so between 5-8 m/s range, it could produce 10% - 30% power than other types of wind turbines.
*Brake device. The blade itself has speed protection, and can configure manual mechanical and electronic brake meantime, in the absence of typhoon and super gust area, manual brake is enough.
*Aluminium alloy steel housing material leads small volume & light weight. Beautiful appearance, low running vibration.
*Flange connection has high strength and easy installation and maintenance.
*Reinforce FRP blades, with optimized aerodynamic shape design and structural design, low start-up wind speed, higher wind energy utilization coefficient, and more annual power generation.
*The rudder adopts automatic yaw design, fold-tail type, it has stronger resistance to typhoon and is safe and reliable in operation.
*Patented NdFeB permanent magnet rotor alternator with special sub-design, effectively reduces the resistance torque of the generatot, and at the same time makes better matching characteristics of the wind wheel and generator, and running reliability.
*optional maximum power tracking intelligent controller, could adjusts current effectively.
*Rotation radius. Because of its design structure and special operating principle, it has a smaller radius of rotation than other types of wind turbines, it saves space, while improving efficiency.
*Power generation curve characteristics. Start wind speed is lower than other types of wind turbines, the power generation increasing rate is relatively gentle, so between 5-8 m/s range, it could produce 10% - 30% power than other types of wind turbines.
*Brake device. The blade itself has speed protection, and can configure manual mechanical and electronic brake meantime, in the absence of typhoon and super gust area, manual brake is enough.
*Aluminium alloy steel housing material leads small volume & light weight. Beautiful appearance, low running vibration.
*Flange connection has high strength and easy installation and maintenance.
*Reinforce FRP blades, with optimized aerodynamic shape design and structural design, low start-up wind speed, higher wind energy utilization coefficient, and more annual power generation.
*The rudder adopts automatic yaw design, fold-tail type, it has stronger resistance to typhoon and is safe and reliable in operation.
*Patented NdFeB permanent magnet rotor alternator with special sub-design, effectively reduces the resistance torque of the generatot, and at the same time makes better matching characteristics of the wind wheel and generator, and running reliability.
*optional maximum power tracking intelligent controller, could adjusts current effectively.
Model | A-100W | A-200W | A-300W | A-400W | |||
Rated power | 100W | 200W | 300W | 400W | |||
Maximum power | 150W | 250W | 350W | 450W | |||
Rated voltage | 12V/24V | 12V/24V | 12V/24V | 24V/48V | |||
Start-up wind spped | 2.0m/s | 2.0m/s | 2.0m/s | 2.0m/s | |||
Rated wind speed | 13m/s | 13m/s | 13m/s | 13m/s | |||
Suvival wind speed | 35m/s | 35m/s | 35m/s | 35m/s | |||
Number of blades | 3/5pieces | ||||||
Blades material | Nylon fiber | ||||||
Fuselage material | Alumminum alloy | ||||||
Generator | Three phase ac permanent magnet generator / Maglev generator | ||||||
Control System | Electromagnetic brake | ||||||
Yaw Mode | The wind Angle automatically | ||||||
Lubrication Mode | Self-lubricating | ||||||
Tower form | Guyed tower / Independent tower | ||||||
Working temperature | -40℃-80℃ | ||||||
1.How can I get the price?
-We usually quote within 24 hours after we get your inquiry(Except weekend and holidays).
-If you are very urgent to get the price, please email us or contact us in other ways so that we can offer you a quote.
2. Can I buy samples placing orders?
-Yes.Please feel free to contact us.
3.What is your lead time?
-It depends on the order quantity and the season you place the order. -Usually we can ship within 7-15 days for small quantity, and about 30 days for large quantity.
4.What is your payment term?
-T/T,Western Union,MoneyGram,and Paypal.This is negotiable.
5.What is the shipping method?
-It could be shipped by sea,by air or by express(EMS,UPS,DHL,TNT,FEDEX and ect).Please confirm with us before placing orders.
6.How do you make our business long-term and good relationship?
-1. We keep good quality and competitive price to ensure our customers benefit ;
-2. We respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from.
