Model | SJ-A45 | SJ-A50 | SJ-A55 | SJ-A60 | SJ-A65 | ||||
Suitable Material | HDPE LDPE LLDPE | ||||||||
Film Width | 100-500mm | 300-600mm | 400-800mm | 500-1000mm | 600-1200mm | ||||
Film Thickness | HD 0.009-0.1mm LD 0.02-0.15mm | HD 0.009-0.15mm LD 0.03-0.15mm | |||||||
Max.Extrusion Output | HD 35kg/hr LD 40kg/hr | HD 40kg/hr LD 50kg/hr | HD 50kg/hr LD 60kg/hr | HD 55kg/hr LD 70kg/hr | HD 55kg/hr LD 70kg/hr | ||||
Screw Diameter | φ45 | φ50 | φ55 | φ60 | φ65 | ||||
Screw L/D Length | 28:1/30:1 | ||||||||
Screw Material | Sacm-645/38 Crmoala | ||||||||
Cylinder Material | Sacm-645/38 Crmoala | ||||||||
Cylinder Cooling | 370w x 1 | 370w x 2 | |||||||
Main Motor | 11kw | 15kw | 18.5kw | 22kw | 22kw | ||||
Temperature Control | 3 | 4 | |||||||
Die Size | HD φ60 LD φ100 | HD φ80 LD φ120 | HD φ80 LD φ180 | HD φ100 LD φ200 | HD φ100 LD φ220 | ||||
Temperature Control | 3 | ||||||||
Air Ring | 1 | ||||||||
Air Blower | 1.5kw | 1.5kw | 2.2kw | 3kw | 3kw | ||||
Roller Width | 600mm | 700mm | 900mm | 1100mm | 1300mm | ||||
Take-up Speed | 10-100m/min | ||||||||
Take-up Motor | 0.75kw | 1.1kw | 1.5kw | 1.5kw | 1.5kw | ||||
Type | Surface Friction Type | ||||||||
Winding Speed | 10-100m/min | 10-80m/min | |||||||
Outline Diameter(LxWxH) | 3.8*2*4.1m | 5*2.2*4.5m | 5.5*2.5*5.2m | 5.8*2.8*6.3m | 5.8*2.8*6.3m | ||||
Company Profile
Packing & Delivery
FAQ
1.Q: is your factory a trading company or a factory?
A: We are a factory, so we have a price advantage. Moreover, we have nearly 33 years of mechanical design and manufacturing experience, and have passed CE, ISO9001 international quality system certification and obtained the right to import and export.
2.Q: how does your company control the quality of machines?
A: Our machines will be strictly inspected by a professional team of engineers to prove and ensure the quality of the machines
3.Q: how about payment terms, payment security and delivery time?
A: We accept a 30% deposit and pay the balance before shipment. And irrevocable letter of credit at sight.
The delivery time is 20 to 30 days. This is based on the order quantity.
4.Q: what is your after-sales service?
A: We have installation engineers. We provide lifelong maintenance for all products sold, and provide scientific, economic and convenient project budget scheme free of charge according to different production conditions and production capacity of customers.
