Product Overview

Description



Product Description






Our product Structure:
1.Truck body is made of 25mm thickness Holypan, front and side wall for maximum weight saving.
2. 3mm steel floor structure or heavy-duty plywood floor structure
3. Aluminum profile all around and aluminum corner cap
4. Kick plate is possible around all walls
5. Rear door can be roll-up or double rear door with three hinges, seals and one camlock per door
6. LED light is possible according to your requirements.


Specification




TRUCK BODY CKD：
THE BOX PANEL CONSTRUCTION: xps sandwich panel, class B2 fire resistance, XPS foam thickness:40mm, density:30kg/m3,
Compressive strength:140-150kpa
outer skin/wall:PPGI(0.33mm thick) Inner wall/lining:PPGIll(0.33mm thick)
Checked steel floor:strong load bearing construction
Door rubble color:gray
Door& door trims: galvanized rear door frame, two door one right side door, Complete with locks,hardware,EPDM door gaskets,and
other accessories
Aluminum profiles.moldings: required c/w self-tap ss screws.rivets and other accessories


NO
box sizeLWH
Side door
FOB QINGDAO PORT
loading quantity
(20ft/40HC container)
10*6*6ft
3040*1830*1830mm
with
15/36units
POP size
3300*1850*1850mm
with
15/36units
12*6*6ft
3650*1830*1830mm
with
12/26units
14*7*7ft
4280*2130*2130mm
with
10/24units
16*7*7ft
4880*2130*2130mm
with
10/22units
17*7*7ft
5150*2130*2130mm
with
9/20units


Name
Drawing number
quantity
Left plate
ZT-3300-8500101
1
Right plate
ZT-3300-8500102
1
Head plate
ZT-3300-8500103
1
Ceiling plate
ZT-3300-8500104
1
Aluminum profile used on the top of the side plate
ZT-3300-8500105
2
Aluminum profile used on the top of the head plate
ZT-3300-8500106
1
Aluminum profile used on the side of the head plate
ZT-3300-8500107
2
Aluminum profile used on the bottom of the side plate
ZT-3300-8500108
2
aluminum profile used on the bottom of the head plate
ZT-3300-8500109
1
Flat batten of side plate
ZT-3300-8500114
2
Flat batten of head plate
ZT-3300-8500115
1
Awning
ZT-3300-8500116
1
Angle iron of connecting the plate
ZT-3300-8500117
2
Rear door assembly
ZT-3300-8500200
1
Side door assembly
ZT-3300-8500300
1
Floor assembly
ZT-3300-8500400
1
Ceiling lamp
1
Switch
1
Lamp wire
15m
Circle angle
2
Height lamp
White, red
4
Self-plugging rivet
300
Neoprene
for the body
2
Polyurethane sealant
for the ceiling
4


Company Profile








Shandong Shenghao Special Purpose Vehicle Co., Ltd. was established in 2020 and more than 78 Employees (6 professional technology R & D). It is located in Zhucheng truck production base, coastal blue economic zone of Shandong Peninsula. At present, our company is mainly engaged in the R & D, manufacturing and sales design of special vehicles, including refrigerated vehicle body, dry truck body, truck body, truck body panel, meat transport vehicle body and other types of van body you want, as well as refrigerated compartment, insulation compartment, wingspan compartment, FRP honeycomb panel compartment, logistics stowage transport vehicle, van transport vehicle, medical garbage vehicle, livestock and poultry transport vehicle, corrugated board, aluminum plate, warehouse grid compartment Hydraulic tail plate transporter, etc.
The company has advanced technology and equipment in the international industry. It adopts today's European and American classic structure and advanced refrigeration compartment plate making technology. The product quality and performance have reached the international leading level. The products sell well at home and abroad and are widely praised by customers. Such as South America, East Asia, Africa, domestic market and Central America.








Cooperative Client








Package & Transport






for truck body,we are transport it by container.
for light truck,we are transport it by container. nude packing
for bigger truck,RO-RO ship it. nude packing




FAQ




1. What are your shipping terms?
Usually, we ship our truck bodies CKD (fully disassembled) or SKD (semi disassembled) by container, and assembled trucks are also
shipped by container, but in small quantities
2. Our truck is a Korean or Japanese brand, does your truck body fit it?
Of course, the general global light truck can be divided into 10ft, 11ft, 12ft, 14ft, 15ft, 16ft, 18ft according to the length of
the cargo box, and the medium truck has 20-32ft. The body can be matched with different brands of trucks just by adjusting the distance of the beam.
3. Is it difficult to install the body CKD or SKD?
Our company has ten years of truck body export experience. We can provide the easiest to assemble truck body ckd
4. Why should you buy from us instead of other suppliers?
For the past 10 years, our company has only produced truck bodies. Our more specialized truck body.
5. What are your payment terms?
T/T 30% as deposit, 70% for copy of bill of lading
6. What are your delivery terms?
EXW,FOB,CFR,CIF
7. What is your delivery time?
Usually within 10 days
8. Can it be produced according to customer requirements?
Yes, we can produce according to customer's technical drawings and specifications
