Welding Column and Boom Industrial Manipulator Robot Arm
- Category: >>>
- Supplier: Wuxi Datang Welding & Cutting Mechanical Equipment Co. Ltd.
Share on (1600536343116):
Product Overview
Description
Product Description
DATANG Welding manipulator includes fixed type,fixed with rotation type and traveling with rotation type.
The boom of machine can weld inside and outside seams of the small tanks,also can weld longitudinal and transverse seams of big tanks.
It has some optional functions,such as Auto-tracking of welding arc.TVmonitor,The flux recovering and conveying system etc.
Packaging & Shipping
welding positioner for sale
1.Outside package:standard export wooden cases
2.Inner package:Stretch film about 14 workdays payments.
DLHMACHINE PARAMETER
| Model | DLH-0810 | DLH-1015 | DLH-1520 | DLH-2020 |
| Column vertical stroke(mm) | 800 | 1000 | 1500 | 2000 |
| Boom horizontal stroke(mm) | 1000 | 1500 | 2000 | 2000 |
| Colimn rotation angle(°) | +-180 | |||
| Cloumn rotation speed(RPM) | Manual | |||
| Boom vertical speed(mm/min) | 1000 | |||
| Boom horizontal speed(mm/min) | 120~1200 VFD(inverter) | |||
| Boom horizontal power(kw) | 0.18 | 0.25 | 0.25 | 0.37 |
| Column vertical power(kw) | 0.55 | |||
| Boom end max loading(kg) | 50 | |||
| Trolley feeding speed(mm/min) | Manual | |||
| Trolley rail span(mm) | 1000 | |||
| Voltage | 380V-3PH-50HZ(Other voltage can customized) | |||
Options:1 Manual cross slide 2.Motorozed cross slide 3.Flux recovery system 4.Auto Tracker syste, 5.Welding osocillator 6.ARC hight controller 7.TV monitoring system 8.Welding machine 9.Wireless controller | ||||
