HY TACH Monitor China manufacturer wholesale industrial Turbine Intelligent monitoring tachometer protector Smart Speed Monitor
- Category: >>>
- Supplier: Dongfang Yoyik (Deyang) Engineering Co. Ltd.
Share on (1600536862597):
Product Overview
Description
Product Description
Description:
The intelligent speed monitoring and protection instrument can expand functions according to the needs of users, with accurate measurement and stable performance. The monitor has the functions of speed measurement, two-level alarm, overspeed protection, analog voltage and current output, sensor fault monitoring, alarm query, self-check and so on. It is suitable for monitoring and protection of rotating machinery in power, textile, petroleum, chemical and other units.
The main function:
1. It has the function of speed measurement and display, which can be 19999r/min~ 45000r/min. It can be displayed by 5-digit digital tube.
2 Alarm function, when the measured forward rotation speed exceeds any alarm setting value, the corresponding alarm indicator light on the front panel is on, and the switch signal is output on the rear panel to protect the monitored equipment.
3 Equipped with a current output interface, which can be connected with computers and other equipment.
4 Parameters can be set through the front panel keys.
The intelligent speed monitoring and protection instrument can expand functions according to the needs of users, with accurate measurement and stable performance. The monitor has the functions of speed measurement, two-level alarm, overspeed protection, analog voltage and current output, sensor fault monitoring, alarm query, self-check and so on. It is suitable for monitoring and protection of rotating machinery in power, textile, petroleum, chemical and other units.
The main function:
1. It has the function of speed measurement and display, which can be 19999r/min~ 45000r/min. It can be displayed by 5-digit digital tube.
2 Alarm function, when the measured forward rotation speed exceeds any alarm setting value, the corresponding alarm indicator light on the front panel is on, and the switch signal is output on the rear panel to protect the monitored equipment.
3 Equipped with a current output interface, which can be connected with computers and other equipment.
4 Parameters can be set through the front panel keys.
Current output | 4-20mA |
Voltage | 200V |
Working temperature | 0~60℃ |
Weight | 1.5KG |
Powe | <10W |
Application Area | Power plant |
Direction for use
The tachometer HY-TACH is equipped with a reluctance speed sensor and a gear speed sensor, which can measure the speed and linear speed of the axles, gears and racks of various rotating machinery.
