Good price diesel heating system vehicle paint booth paint spray booth with filter system
- Category: Spray Booths >>>
- Supplier: Shandong,UM,Technology,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
♥ Tips:We can also customize the spray booth as your requirments.
Welcome to our shop,we can provide rock wool wallboard, EPS wallboard, electric heating, diesel heating, natural gas heating, all kinds of filtration systems. We can also design a suitable spary booth for you according to your actual site.
Contact us and you'll be pleasantly surprised.
Specification
Outside size | 7000 × 4000 × 3250 mm (L×W×H) | ||||||
nside size | 6900 × 3900 × 2600 mm (L×W×H) | ||||||
Entrance door | 3000 × 2500 mm × 3 folds | ||||||
Emergency door | 650 × 2000 mm ×1 fold, with handle and anti-explosion lock | ||||||
Cabin system | wall panel | 50 mm EPS panel + 0.35 mm galvanized steel plate | |||||
basement | - steel structure, 300 mm height - 2 rows of steel grille + 3 rows of diamond plate floor - diamond plate ramp, 1800 mm × 600 mm ×2 pc | ||||||
Ventilation system | inlet fan | 2 × 4KW YDW centrifugal fans, total air capacity: 25000 m3/h/set | |||||
outlet fan | optional | ||||||
airflow speed | 0.35 m/s, ventilation rate: 280 time/h | ||||||
Heating system | 1KW × 3 pc × 8 units infrared lamps for heating | ||||||
Lighting system | ceiling light | LED lights: 16W × 3 pc × 8 units | |||||
Filtering system | primary filter | to filter granules > 10μm, filtering rate > 83% | |||||
ceiling filter | to filter granules > 4μm, filtering rate > 98% | ||||||
Control system | lighting, spraying, heating, temperature controller, time setting, emergency stop, etc. | ||||||
Working voltage | 380V/220V, 50Hz/60Hz, 3 phase | ||||||
Details Images
Why Choose Us
FAQ
Q: How do you ganrantee the production quality?
A: We have an independent QC team. Our QC teams do sample inspection, part inspection during production and 100% final inspection before the shipment.
Q: May I know the Lead time?
A:The lead time of our machine is 10-25 days. When you order more, we need to check the production schedule.
Q: What is the regular color? May I order a special color I like?
A: The regular color is Blue, Orange, White, Red. Also we can do customize one for you.
Q: Can you supply OEM service?
A: Yes, we can, some customers prefer that use their Logo, their color. And we are glad to help them open their market.
Q: What is the warranty time?
A: Warranty time is 24 months. Parts have free replacement when damaged during this time.
A: We have an independent QC team. Our QC teams do sample inspection, part inspection during production and 100% final inspection before the shipment.
Q: May I know the Lead time?
A:The lead time of our machine is 10-25 days. When you order more, we need to check the production schedule.
Q: What is the regular color? May I order a special color I like?
A: The regular color is Blue, Orange, White, Red. Also we can do customize one for you.
Q: Can you supply OEM service?
A: Yes, we can, some customers prefer that use their Logo, their color. And we are glad to help them open their market.
Q: What is the warranty time?
A: Warranty time is 24 months. Parts have free replacement when damaged during this time.
