DC to AC 3 Phase 380V Solar Pump Inverter Output Agriculture Solar System Controller Inverter

Product Overview

Description

Model	Rated Output Current(A)	Maximum DC Input Current(A)	DC Input Voltage Range(V)	Recommended Solar Power (KW)	Recommended Solar Open Circuit Voltage(VOC)	Pump Power(kW)
PV150I-2S:DC input 70-450V DC or AC input single phase 220V;Output single phase 220VAC
PV150A-2S-0.7B	7.5	10.6	70-450	1	360-430	0.75
PV150A-2S-1.5B	10.5	10.6	70-450	2	360-430	1.5
PV150A-2S-2.2B	17	21.1	70-450	2.9	360-430	2.2
PV150A-2S-4.0B	25	31.7	70-450	5.2	360-430	4
PV150A-2S-5.5B	32	42.2	70-450	7.2	360-430	5.5
PV150A-1S :DC input 70-450V or AC input single phase 110-220V;Output three phase 110VAC
PV150A-1S-1.5B	7.5	10.6	70-450	0.6	170-300	0.4
PV150A-1S-2.2B	9.5	10.6	70-450	1	170-300	0.75
PV150A-2S :DC input 70-450V or AC input single phase 220V ;Output three phase 220VAC
PV150A-2S-0.4B	2.5	10.6	70-450	0.6	360-430	0.4
PV150A-2S-0.7B	4.2	10.6	70-450	1	360-430	0.75
PV150A-2S-1.5B	7.5	10.6	70-450	2	360-430	1.5
PV150A-2S-2.2B	9.5	10.6	70-450	2.9	360-430	2.2
4T :DC input 230-800V or AC input three phase 380V ;Output three phase 380VAC
PV150A-4T-0.7B	2.5	10.6	230-800	1	600-750	0.75
PV150A-4T-1.5B	4.2	10.6	230-800	2	600-750	1.5
PV150A-4T-2.2B	5.5	10.6	230-800	2.9	600-750	2.2

4T :DC input 230-800V or AC input three phase 380V ;Output three phase 380VAC
PV500-4T-4.0B	9.5	10.6	230-800	5.2	600-750	4
PV500-4T-5.5B	13	21.1	230-800	7.2	600-750	5.5
PV500-4T-7.5B	17	21.1	230-800	9.8	600-750	7.5
PV500-4T-011B	25	31.7	230-800	14.3	600-750	11
PV500-4T-015B	32	42.2	230-800	19.5	600-750	15
PV500-4T-018B	37	52.8	230-800	24.1	600-750	18.5
PV500-4T-022B	45	63.4	230-800	28.6	600-750	22
PV500-4T-030B	60	95	230-800	39	600-750	30
PV500-4T-037	75	116.2	230-800	48.1	600-750	37
PV500-4T-045	91	137.2	230-800	58.5	600-750	45
PV500-4T-055	112	169	230-800	71.5	600-750	55
PV500-4T-075	150	232.3	230-800	97.5	600-750	75
PV500-4T-090	176	274.6	230-800	117	600-750	90
PV500-4T-110	210	337.9	230-800	143	600-750	110
PV500-4T-132	253	401.3	230-800	171.6	600-750	132
PV500-4T-160	304	485.8	230-800	208	600-750	160
